Marine Battery Systems LFP ESS Cabinet
Which ships are suitable for marine batteries?
The application of Marine LFP Battery Pack are suittable for
Tugboat,Ropax Vessel,Car Ferry ,MPV Cargo Vessel,Offshore Supply Vessel,Platform Supply Vessel,Fish Farm and so on
Fetures:
1.Customized large scale energy capacity
2.High efficiency and safety
3.Shells have waterproof and dustproof ability
4.Max discharge current: 2240A(1C)
| Battery type | LiFePO4, prismatic, grade A+ | System voltage | 576V |
| System rated capacity | 2240Ah | System rated energy | 1290KWh |
| Maximum continuous discharge current | 2240A(1C) | Standard discharge current | 1120A(0.5C) |
| System Weight | 1200KG | System Size | 5200*550*2450mm |
| Motor Power | 1200KW | Charger Power | 200KW |
| Working ambient temperature | - 20℃~+45℃ | Storage ambient temperature | - 20℃~+60℃ |
1200KW-1.29MWh Marine Battery Power System, for pure electric boats as the power source, and also supply the auxiliary devices in the boats. The BESS LFP battery system consists of two stacks, each with the same structure, equipped with four units BMS and a set of display controllers.
