220V to 5V 8A Switching Mode Power Supply

220V to 5V 8A Switching Mode Power Supply

The switch mode transformer is a high quality, black or white 5Volt 8.0Amp dc output 40w desktop style constant voltage smps adapter series with green LED indication for power on. This ac dc adaptor 5v accepts full range from 100V to 240V AC input voltage and lock type DC connector options. The power adaptor plug provides 3 years warranty and certified for UL/cUL, GS, CE, PSE, KC, CCC, RoHS safety approvals for I.T.E applications. The transformer adapter is also a class I or II rated and equipped with three standard AC inlets options for IEC320-C6, IEC320-C8 and IEC320-C14.

Features

◆ Desktop style, up to 40W continuous power

◆ Universal AC input/ Full range

◆ Level VI energy efficiency

◆ Protections: Short circuit / Over voltage / Over current

◆ Class II power (without earth pin): IEC320-C8;

ClassⅠpower(with earth pin): IEC320-C6 or IEC320-C14

◆ Pass LPS (Limited power source)

◆ Compact Size, fully enclosed plastic case

◆ LED indicator for power on

◆ 100% full load burn-in test

◆ 3 years Warranty

Specifications

Dimensions LxWxH (in): 5.511 x 2.362 x 1.377
Dimensions LxWxH (mm): 140 x 60 x 35
Color: Black/ White
Input: 100-240V AC±10% 50/60Hz
Output: Constant voltage mode and Single output
Working Environment: -10℃-40℃ 5%-90%RH
Storage Environment: -20℃-85%℃ 5%-95%RH
No load power consumption: below 0.1W
Overshoot: 15% Max. When power supply at turn on or turn off
Cooling method: Natural Cooling down
RoHS compliant: Yes
Ripple/Noise:<150mV
Accuracy:±1%
Safety Standards: UL1310, UL62368, IEC/EN62368 60950, IEC61558, AS/NZS62368, GB4943, J62368, K60950
Safety Approvals: UL CUL CE KC KCC GS SAA RCM CB FCC PSE CCC RoHS

Applications: 3D Printer, Ultrasonic Humidifier, LCD Monitor, LED Lights, HDD Enclosure, CCTV, Car DVR, Digital Photo Frame, Mobile Phone, Laptop, Tablet PC, Refrigerators, Portable DVD, Set Top Box, Radio, Security System Products, Massage Products, Electronics Products etc
