Solar pv connectors EVO2 wire harness
Solar pv connectors EVO2 wire harness 1500V 30A professional manufacture,Xime Connector Technology is a professional manufacturer of industrial sensor waterproof connectors M5,M8,M9,M12,M16,M23,providing threaded waterproof connectors,m12 adapter,electronic harness design and development,2D 3D design services,solar panel cable,solar connection,solar connector,Medical plugs equipment connector,military equipment waterproof box,car wiring harness,etc.
The evo2 wire is the latest addition to the xime Connectors PV connector portfolio.
· Internationally certified with IEC, UL, JET, TUV
· Approved for 1500 V DC (IEC, JET), 1500 V DC (UL) unrestricted access
· Suited for all climatic environments thanks to resistance to UV, ammonia, salt-mist spray and high IP class (IP69K)
· Available as a field and preassembled connector, evo2 wire tools can be used
|
Connector system |
|
￠4mm |
|
|
|
Rated voltage |
|
|
1500V DC(IEC)1) |
|
|
|
1500V/1500 DC(UL)2) |
|||
|
Rated current |
|
|
17A(1.5㎜2) |
|
|
|
22A(2.5㎜2;14AWG) |
|||
|
|
30A(4㎜2;6㎜2;12AWG,10AWG) |
|||
|
Test voltage |
|
|
8kV/8KV(50Hz,1min.) |
|
|
Ambient temperature range |
|
|
-40℃-+90℃(IEC) |
|
|
|
-40℃-+75℃(UL) |
|||
|
Upper limiting temperature |
|
+105℃(IEC) |
|
|
|
Degree of protection,mated |
|
IP67,IP68(1h/1m) |
||
|
Contact resistance of plug connectors |
|
0.5mΩ |
|
|
|
Safety class |
|
|
Ⅱ |
|
|
Contact material |
|
Messing,verzinnt |
||
|
|
Copper Alloy,tin plated |
|||
|
Insulation material |
|
|
PC/PA |
|
|
Locking system |
|
|
Snap-in |
|
|
Flame class |
|
|
UL-94-V0 |
|
