Extruded Polymer Plastic Delrin Plate Acetal Pom Sheet

Extruded Polymer Plastic Delrin Plate Acetal Pom Sheet

$3.45

≥500 Kilogram

Min. Order:: 500 Kilogram

Min. Order:: 500 Kilogram

Transportation:: Ocean, Land, Air, Express, Others

Port:: Shenzhen, China

Quantity:

Your message must be between 20 to 2000 characters

Contact Now

Basic Info

Supply Ability:	3000 tons per month
Payment Type:	L/C,T/T
Incoterm:	FOB,CFR,CIF,EXW
Transportation:	Ocean,Land,Air,Express,Others
Port:	Shenzhen,China

Product Description

Extruded Natural or Black Polymer Plastic Delrin Plate Acetal Copolymer Pom Sheet

POM-C sheet is a semicrystalline thermoplastic and is characterized by a low coefficient of friction and good wear properties, and good wear properties,unaffect-ed by wet environments.POM plate offers good resistance to a wide range of chemicals including many solvents. A Delrin plate provides high strength and stiff-ness coupled with easy machineability. AHD is also noted for its high me-chanical strength,heat resistance and good antifriction properties. A For parts which need to be dimensionally stable even exposed to humidity or wet envi-ronments, POM-C offers better hot water,ther- mal and chemical resistance than POM-H.

Main Properties:

Strong mechanical strength

High rigidity and hardness
Excellent elasticity
Good sliding performance
Abrasion resistance and creep resistance
High impact strength
Good dimensional stability,
Excellent mechanical performance
Physiological inertia and suitable to contact with food

Application:

POM is widely used for sliding and rotating machinery, precision components, gears and bearings in automotive, electronics, garment, medical care, machinery, ans sports apparatus

Rom1

Spec

Item name	POM-C sheet
Type:	extruded
Diameter:	Ø15---200mm
Length:	1000mm
Density:	1.2 g/cm³
Color:	White, black
Brand name:	AHD
Material:	100% virgin material
Sample:	FREE
Acid resistance:	YES
Food Contact	YES

Physical Datasheet:

Item	POM sheet
Color:	white
Proportion:	1.41g/cm³
Heat resistance (continuous):	115℃
Heat resistance (short-term):	140℃
Melting point:	165℃
Linear thermal expansion coefficient (average 23~100℃):	110×10^-6 m/(m.k)
Average 23--150℃	125×10^-6 m/(m.k)
Flammability(UI94):	HB
Tensile modulus of elasticity:	3100MPa
Dipping into water at 23℃ for 24h	20%
Dipping into water at 23℃	0.85%
Bending tensile stress/ Tensile stress off shock	68/- Mpa
Breaking tensile strain	˃35%
Compressive stress of normal strain-1%/2%:	19/35 MPa
Pendulum gap impact test	7 KJ/m²
Friction coefficient:	0.32
Rockwell hardness:	M84
Dielectric strength:	20 kv/mm
Volume resistance:	10 ¹⁴Ω×cm
Surface resistance:	10 ¹³Ω
Relative dielectric constant-100HZ/1MHz:	3.8/3.8
Critical tracking index(CTI)	600
Bonding capacity:	+
Food contact:	+
Acid resistance:	+
Alkali resistance	+
Carbonated water resistance:	+
Aromatic compound resistance:	+
Ketone resistance:	+

Size Tolerance:

Thickness	Size 1000x2000mm	N.W (KGS)
1	ok	3.06
2	ok	6.12
3	ok	9.18
4	ok	12.24
5	ok	15.3
6	ok	18.36
8	ok	26.29
10	ok	30.50
12	ok	38.64
15	ok	46.46
20	ok	59.76
25	ok	72.50
30	ok	89.50
35	ok	105.00
40	ok	118.83
45	ok	135.00
50	ok	149.13
70	ok	207.00
60	ok	232.30
80	ok	232.30
90	ok	268.00
100	ok	299.00

Goods Photos:

Delrin sheet

POM sheet

acetal plate

About us:

Established in Shenzhen in 1994, our company is a comprehensive company that is engaged in the R&D, production and distribution of semi-finished engineering plastic in China, including POM sheet, PC sheet, ABS sheet, PP sheet, HDPE sheet, PA6 sheet and PU sheet & rod. Our company has more than 250 plastic production lines of imported manufacturing equipment, and covers an area of 25000 square meters. With over 200 employees (a number of them are senior engineers), together with many years of experience and customers' feedback, we have been a leader in plastic industry field for the constant perfection of our service network, technical level and product scope.

We've obtained independent import and export rights and established various branches all over the country. Our products sell well in Europe, America and Southeast Asia. The proportion of export has increased over years.

We can meet customers' requirements, and we can find out the best solution for each application. Besides, we can also help our customers to maintain the competitive position and have every customer obtain benefits from the best products.
