Black Rigid PC Polycarbonate Roofing Sheets
- Min. Order:
- 100 Kilogram
- Min. Order:
- 100 Kilogram
- Transportation:
- Ocean, Land, Air, Express
- Port:
- Shenzhen, Guangzhou
Your message must be between 20 to 2000 characters
Contact NowPlace of Origin: | China |
---|---|
Productivity: | 3000tons/month |
Supply Ability: | 3000tons/month |
Payment Type: | L/C,T/T |
Incoterm: | FOB,CFR,CIF,EXW,FCA,DDU |
Certificate: | SGS, TUV |
HS Code: | 392061 |
Transportation: | Ocean,Land,Air,Express |
Port: | Shenzhen,Guangzhou |
Plastic is an incredibly versatile material that can be used in countless applications and projects. One of the most common forms of plastic is a group of thermoplastic polymers known as polycarbonates (PC). This synthetic resin is a naturally transparent amorphous thermoplastic that can be used to produce a variety of precision machined parts and products, but it’s also frequently used as a replacement for acrylic, glass, and polyethylene. Polycarbonate sheets offer a wide variety of characteristics and features that are well-suited to numerous applications and industries, including agricultural, automotive, construction, electrical, medical, and security, to name a few.
Specification:
Physical Datasheet:
Features and Benefits:
Item
PC ( Polycarbonate) sheet
Type
extruded
Thickness
3--100mm
Size
1220X2440MM, 1000X2000MM
Color
Transparency
Proportion
1.2g/cm³
Heat resistance (continuous)
125℃
Heat resistance (short-term)
135℃
Melting point
_
Glass transition temperature
150℃
Linear thermal expansion coefficient
(average 23~100℃)
65×10-6m/(m.k)
Average 23--150℃
65×10-6m/(m.k)
Flammability(UI94)
HB
Tensile modulus of elasticity
2400MPa
Dipping into water at 23℃ for 24h
0.13
Dipping into water at 23℃
0.35
Bending tensile stress/ Tensile stress off shock
70/- Mpa
Breaking tensile strain
>50%
Compressive stress of normal strain-1%/2%
18/35 MPa
Pendulum gap impact test
9 KJ/m2
Friction coefficient
0.55
Rockwell hardness
M75
Dielectric strength
28 kv/mm
Volume resistance
≥10 15Ω×cm
Surface resistance
≥10 15Ω
Relative dielectric constant-100HZ/1MHz
3/3
Critical tracking index(CTI)
600
Bonding capacity
+
Food contact
+
Acid resistance
+
Alkali resistance
-
Carbonated water resistance
0
Aromatic compound resistance
-
Ketone resistance
-
- Virtually unbreakable
- High impact resistance
- High clarity and light transmission
- UV protective layer (1 or 2 sided)
- High flame resistance
- Half the weight of glass
- Easy to machine, handle, and install
Application:
- Fabricating: sawing, routing, shearing, laser cutting, die cutting, and drilling
- Fastening: mechanical fastening, solvent bonding, transfer tape bonding, and welding
- Finishing: sanding, jointing/planing, solvent polishing, hot stamping, screen printing, painting,
- Forming: brake bending, cold bending, thermoforming, molding, drape forming, and strip heating
- Glazing: curtain-wall framing with either a wet or dry glazing system
Packing:
1.one pcs sheet packing: covered with craft paper or PE film,the covered film with AHD logo.
2.with pallet Bulk cargo packing: 1.5-2 tons per pallet, use Iron pallets on bottom, with packaging waterproof fabric ,film packages and all around ensure transportation security and prevent damage for the products.
3.Full container load packing: 20-26 tons of a 20 foot container.
Our service:
1. Quotation reply: Answered within 24h.
2. MOQ: For general size, MOQ can be 100KGS.If you need to customize products, MOQ is 1000KGS of each specification.
3. Sample: samples can be sent free, you just need pay for express fee.
4. Mixed batch: Support mixed batch.
5. After sales service: Your satisfaction is our final goal. You can always get a solution from us when you have questions after receiving the goods
FAQ:
Q1: Are you a factory or trade company?
A1: we are a manufacturter for semi-finished engineering plastic sheet & rod like "
Polypropylene rod and sheet ,Nylon plate and bar,Pa6 board and bar,Abs Plastic Sheet and rod, POM plate and bar, Polycarbonate plate and rod , PEI sheet, HDPE board and rod"etc since 1994.
Q2: Is your sample free?
A2:Yes, our samples are free, but the shipping cost is paid by the buyer.
Q3: What about the MOQ ?
A3:In addition to the sample, the minimum order quantity for a regular size product is 100kgs.
Q4: What about the packing ?
A4: As per factory's exported standard, usually use steel pallets.
Q5: What about the payment term ?
A5:we accept payment by L/C , T/T, usually 30% deposit is requested before production. 50% deposit is request for customzied items.
Q6: What's your delivery time?
A6:For samples: within 1-3 working days; For orders: within 7-30 working days.
