Customized Nylon sheet Polyamide PA6 PA66 Plastic board

Customized Nylon sheet Polyamide PA6 PA66 Plastic board

$1.00 - $5.00/Kilogram

Min. Order:: 200 Kilogram

Min. Order:: 200 Kilogram

Transportation:: Ocean, Land, Air, Express, Others

Port:: Shenzhen port or according to the requirement from customer

Quantity:

Your message must be between 20 to 2000 characters

Contact Now

Basic Info

Supply Ability:	3000 tons per month
Payment Type:	L/C,T/T,Paypal,Others
Incoterm:	FOB,CFR,CIF,EXW,DDP,DDU,Express Delivery
Transportation:	Ocean,Land,Air,Express,Others
Port:	Shenzhen port or according to the requirement from customer

Product Description

Customized Nylon sheet Polyamide PA6 PA66 Plastic board

Introduction:

PA is recognized as the most widely used and known engineering plastic in the current market.

PA6 has the best performance, very tough, even at low temperatures, and high surface hardness, mechanical lower shock, and abrasion resistance. Combined with these characteristics and good insulation, and chemical properties, it has become common-level materials. It’s widely used in a variety of mechanical structures and spare parts. Compared to PA6, PA66 own the higher hardness, rigidity, better resistance to wear and heat deflection temperature. Temperature resistance from -40°C to 110 °C.

Physical Datasheet:

Item	Nylon (PA6) sheet
Color:	White,Black, Blue
Proportion:	1.15g/cm³
Heat resistance (continuous):	85℃
Heat resistance (short-term):	160℃
Melting point	220℃
Linear thermal expansion coefficient (average 23~100℃):	90×10-6 m/(m.k)
Average 23--150℃	105×10-6 m/(m.k)
Flammability(UI94):	HB
Tensile modulus of elasticity:	3250MPa
Bending tensile stress/ Tensile stress off shock	76/- Mpa
Pendulum gap impact test	5.5 KJ/m2
Rockwell hardness:	M85
Dielectric strength:	25 kv/mm
Volume resistance:	10 ¹⁴Ω×cm
Surface resistance:	10 ¹³Ω×cm
Relative dielectric constant-100HZ/1MHz:	3.9/3.3
Critical tracking index(CTI)	600
Bonding capacity:	+
Food contact:	+
Acid resistance:	-
Alkali resistance	+
Carbonated water resistance:	+/0
Aromatic compound resistance:	+/0
Ketone resistance:	+

Extruded Nylon 6 Sheet Photo: Plastic Polyamide PA6 Nylon Pad Plate Sheet
