Product Description

High brightness enables longer viewing distance and ensures the spectators far from the screen can still enjoy what is shown.

Superb performance/price ratio offers you both top notch quality and reasonable price, maximizing the value of your investment.

Outdoor die-casting aluminum LED panel

Die-casting aluminum LED panel, the quality is stable.
Panel size is 500x1000mm , each panel weighs 13kg,easy to lifting and install.
The supper thin design, it is suitable for all kinds of condition for installation.

Seamless Splicing

The new and special fast lock design make the installation become easy, also the fast lock handle just suitable for hand, it become more convenient.
Each cabinet with 4 pcs fast lock, kept the stable of LED display, also make the seamless installation.

Specification

Model	ORD-7.8	ORD-10.4	ORD-15.6
Pixel Pitch	7.8125mm	10.416mm	15.625mm
Cabinet Dimension	500*1000mm	500*1000mm	500*1000mm
Cabinet Resolution	64*128px	48*96px	32*64px
Cabinet Weight	13kg	13kg	10kg
Cabinet Material	aluminum	aluminum	aluminum
Ingress Protection(front/rear)	IP65/IP54	IP65/IP54	IP65/IP54
Brightness	>5500nits	>5500nits	>5500nits
Viewing Angle(H/V)	140°/140°	140°/140°	140°/140°
Frame Refresh	≥ 60Hz	≥ 60Hz	≥ 60Hz
Data Refresh Rate	>1500Hz	>1500Hz	>1500Hz
Gray Scale	16bit	16bit	16bit
Power Consumption(avg.)	420w/m2	300w/m2	320w/m2
Temperature(operating/storage)	-20~50°C / -40~60°C	-20~50°C / -40~60°C	-20~50°C / -40~60°C
MTBF	≥1000hrs	≥1000hrs	≥1000hrs
Life Span	≥100000hrs	≥100000hrs	≥100000hrs
Pixel Failure	<0.0003	<0.0003	<0.0003

outdoor High Brightness Stage LED Display

Good after-sales service

1. Three-years warranty for the entire system, except human factors and force majeure Guarantee.
2.One of the year the quality, maintenance of life, and to ensure the maintenance time in the contract.
3.The warranty period: solving problems for users through telephone, fax or email. Update the software for free.
4.As to product quality problems caused by the design, manufacturing, technology installation, equipment, replacement and maintenance are free.

System damage caused by force majeure (flood, fire, earthquake, war, and so on) as well as users) artificial disturbance (construction, cleaning) should be coordinated by the two parties to résoudre.Entretien
5.Life long for the system: after the warranty, we charge only the cost of equipment.
