P10 SMD3535 Outdoor Rental LED Display

Get Latest Price

Payment Type:: L/C, T/T

Incoterm:: FOB, CFR, CIF, FCA, CPT

Min. Order:: 1 Piece/Pieces

Min. Order:: 1 Piece/Pieces

Delivery Time:: 30 Days

Transportation:: Ocean, Land, Air

Port:: ShenZhen, GuangZhou

Quantity:

Your message must be between 20 to 2000 characters

Contact Now

Basic Info

Place of Origin:	CHINA
Productivity:	6000m²/Month
Supply Ability:	6000m²/Month
Payment Type:	L/C,T/T
Incoterm:	FOB,CFR,CIF,FCA,CPT
Certificate:	CCC,FCC,ETL,CE,EMC,ROHS
HS Code:	8528591090
Transportation:	Ocean,Land,Air
Port:	ShenZhen,GuangZhou

Product Description

High gray level high refresh rate P10 SMD3535 Outdoor Rental LED Display

Product

High refresh rate : >1500Hz,no scanning line when photographed.
High gray level: 256 RGB each, display 16.7million colors, vivid and perfect video effect.
High resolution and high contrast ratio : make the picture more delicate.
High Brightness: >6500nits,brightness automatically adjusted, Clearly visible even in direct sunlight.
Wide viewing angle: both horizontal and vertical viewing angles are 140°.
Life Span : ≥100000hrs.
Lower power consumption: Average Power Consumption is 200w/m²,energy saving and environmental protection.
Ultra slim and lightweight : 13kg per Cabinet Weight (640x640mm), greatly saves transportation costs and installation costs.
Rental die-casting aluminum structure: high strength, strong toughness, high precision, not easy to deform.
Seamless splicing : give you a better visual experience.
Quick lock system, fast installation and dismantlement : complete the installation and dismantlement in a few seconds.

Technical Parameters

Model	ORB-10
Pixel Pitch	10mm
Pixel Density	10000 pixels/m²
LED Type	SMD3535
LED Configuration	1R1G1B
Cabinet Dimension	640mmx640mm
Cabinet Resolution	64*64pixels
Cabinet Weight	13kg
Cabinet Material	die casting aluminum
Ingress Protection(front/rear)	IP65/IP54
Brightness	>6500nits
Viewing Angle(H/V)	140°/140°
Driving Method	1/4 Scan
Frame Refresh	≥ 60Hz
Data Refresh Rate	>1500Hz
Gray Scale	16bit
Power Consumption(avg.)	200w/m²
Input Voltage	AC 110/220±10%, 50~60Hz
Temperature(operating/storage)	-20~50°C / -40~60°C
Humidity(operating/storage)	10%~90%RH / 10%~85%RH
MTBF	≥1000hrs
Life Span	≥100000hrs
Pixel Failure	<0.0003

Factory Tour

quick installation show stage video wall

Aging display

vivid pictures high gray scale led video wall

Service system

WHY CHOOSE US?

Founded in 2005, Shenzhen Bako vision Technology Co., Ltd. is a national high-tech enterprise specializing in R&D, production, sales and solutions of LED optoelectronic products.

The company has a number of the latest imported production equipment, including the latest imported high-speed patch equipment, wave soldering equipment, braiding equipment, automatic glue filling equipment, LED lamp bead oven, etc.; LED display detection equipment, including LED display brightness detection equipment, LED outdoor screen waterproof test equipment, LED display brightness and chromaticity correction equipment.

FAQ

Q1: What's the warranty of your LED Display Screen ?
A1: We have a 3-year warranty for our led display screen, and 100,000 hours life span of the led lamps.
Q2: What about your pre-sale service and post-sale service?
A2: For pre-sale service: We have a professional sales team and a 12 years technical team who are willing to answer your question 24/7. We can offer a whole complete solution for your project!

For post-sale service: We can instruct you how to use, adjust the screens, and change the boken modules with spare parts.

Also, we can send technicals to your country to solve problems. Mostly, our led display will not have big problems within warranty time!

Q3: How can you ensure the led display product quality?
A3: Our led display screen quality is our core competence, for 12 years, what we rely on.

We have each standard process to make quality products.

If any quality failures within warranty time, We will refund you.
