P3.9 SMD2525 Outdoor Rental LED Display
- Payment Type:
- L/C, T/T
- Incoterm:
- FOB, CFR, CIF, FCA, CPT
- Min. Order:
- 1 Piece/Pieces
- Min. Order:
- 1 Piece/Pieces
- Delivery Time:
- 30 Days
- Transportation:
- Ocean, Land, Air
- Port:
- ShenZhen, GuangZhou
Your message must be between 20 to 2000 characters
Contact NowPlace of Origin: | CHINA |
---|---|
Productivity: | 6000m²/Month |
Supply Ability: | 6000m²/Month |
Payment Type: | L/C,T/T |
Incoterm: | FOB,CFR,CIF,FCA,CPT |
Certificate: | CCC,FCC,ETL,CE,EMC,ROHS |
HS Code: | 8528591090 |
Transportation: | Ocean,Land,Air |
Port: | ShenZhen,GuangZhou |
The Rental Display cabinet is light and thin, which can be quickly installed and disassembled, convenient to transport, and easy to maintain,quickly welcomed by people.
Product Description
- Optional of Convex Shaped, Concave Shaped and Wave Shaped screens.
- Ultra slim and lightweight : 8kg per Cabinet Weight(500x500mm), 14kg per Cabinet Weight(500x1000mm), greatly saves transportation costs and labor costs.
- Rental die-casting aluminum structure: rock solid, not easy to deform.
- Seamless splicing : give you a better visual experience.
- Quick lock system, easy installation : quick installation, complete the installation in a few seconds
- High refresh rate : >1500Hz,no scanning line when photographed.
- High gray level : 256 RGB each, display 16.7million colors, vivid and perfect video effect.
- High contrast ratio : make the picture more delicate.
- Wide viewing angle: both horizontal and vertical viewing angles are 140°
- Working status indicator available.
- High Ingress protection: IP65/IP54(front/rear), IPXX-The first X indicates the dust level, and the second X indicates the waterproof level. IP65 means the product can completely prevent dust from entering and can be washed with water without any damage.IP54 means the product can prevent harmful dust accumulation and the liquid splashes from any direction to the outer shell without damage.
- High Brightness: >6500nits,brightness automatically adjusted, Clearly visible even in direct sunlight.
- Lower power consumption: Average Power Consumption is 420w/m²,energy saving and environmental protection.
- Long life :life Span ≥100000hrs.
- Pixel Failure <0.0003.
- High resolution: The most apparent features of the new generation of LED display, clearer picture.
Technical Parameters
Model
ORA-3.9
Pixel Pitch
3.9mm
Pixel Density
65536 pixels/m²
LED Type
SMD2525
LED Configuration
1R1G1B
Cabinet Dimension
500x500mm/500x1000mm
Cabinet Resolution
128*128px/128*256px
Cabinet Weight
8kg/14kg
Cabinet Material
die casting aluminum
Ingress Protection(front/rear)
IP65/IP54
Brightness
>6500nits
Viewing Angle(H/V)
140°/140°
Driving Method
1/8 Scan
Frame Refresh
≥ 60Hz
Data Refresh Rate
>1500Hz
Gray Scale
16bit
Power Consumption(avg.)
420w/m²
Input Voltage
AC 110/220±10%, 50~60Hz
Temperature(operating/storage)
-20~50°C / -40~60°C
Humidity(operating/storage)
10%~90%RH / 10%~85%RH
MTBF
≥1000hrs
Life Span
≥100000hrs
Pixel Failure
<0.0003
