P15.6mm Static driving Outdoor Billboard LED Display

P15.6mm Static driving Outdoor Billboard LED Display

Get Latest Price

Payment Type:: L/C, T/T

Incoterm:: FOB, CFR, CIF, FCA, CPT

Min. Order:: 1 Piece/Pieces

Min. Order:: 1 Piece/Pieces

Delivery Time:: 30 Days

Transportation:: Ocean, Land, Air

Port:: Shenzhen, Guangzhou

Quantity:

Your message must be between 20 to 2000 characters

Contact Now

Basic Info

Place of Origin:	China
Productivity:	6000 ㎡/ Month
Supply Ability:	6000 ㎡/ Month
Payment Type:	L/C,T/T
Incoterm:	FOB,CFR,CIF,FCA,CPT
Certificate:	CCC,FCC,ETL,CE,EMC,RoHS
HS Code:	8528591090
Transportation:	Ocean,Land,Air
Port:	Shenzhen,Guangzhou

Product Description

P15.6mm Static driving Outdoor Billboard LED Display

Product Features:

Mainly for outdoor advertising, information publishing, journalism and communication in some places, such as cultural square, traffic arteries, stations, terminals, information centers, entertainment venues, shopping, centers, commercial city and etc.

1. High brightness SMD3535 LED is used for outdoor LED display, keeps the display content visible even if facing the strong sunshine directly.

2. With Anti-UV ray mask, the color of the mask would never change even if under exposure of UV ray.

3. Weatherproof design, completely outdoor use.

4. Easy for assembling and connection with the connector added.

5. High color uniformity and clear image can bring you a vivid audio visual effect.

6. Rear access are available.

7. The LED Chips that we use have the advantages of large viewing angle, low power consumption and good color uniformity.

8. Use the same level of red, green and blue LED chips, which makes the image display of whole LED display more excellent and uniform.

9. The maintenance of pixel and single LED has been realized.

10. Good quality raw material, accurate technique and careful inspection insures the high quality of LED display.

11. Relatively low cost (factory)

12. Stable capability

13. High brightness, high definition of displaying image.

14. Easy installment and low maintenance cost

15. Cabinet size double fan design, speed up internal air circulation, auxiliary heat make the screen more stable and reliable.

billboard led display

LED Billboard display

Model	ODC-15.6	ODC-20	ODC-25	ODC-31.25
Pixel Pitch	15.6mm	20mm	16/25mm	31.25mm
Pixel Density	4109px/m²	2500 px/m²	2500px/m²	1024 px/m²
LED Type	DIP346	DIP346	DIP346	DIP346
LED Configuration	1R1G1B	1R1G1B	1R1G1B	1R1G1B
Cabinet Dimension	1500*250mm	1000*320mm	1000*320mm	1000250mm /1500250mm
Cabinet Resolution	96*16px	50*16px	60*20px	328px/488px
Cabinet Weight	6.0kg	6kg	6.8kg	3.5kg/5kg
Cabinet Material	aluminum	aluminum	aluminum	aluminum
Ingress Protection(front/rear)	IP65/IP54	IP65/IP54	IP65/IP54	IP65/IP54
Brightness	>6500nits	>6500nits	>6500nits	>6500nits
Viewing Angle(H/V)	110°/70°	110°/70°	110°/70°	110°/70°
Driving Method	Static driving	Static driving	Static driving	Static driving
Frame Refresh	≥ 60Hz	≥ 60Hz	≥ 60Hz	≥ 60Hz
Data Refresh Rate	>1500Hz	>1500Hz	>1500Hz	>1500Hz
Gray Scale	16bit	16bit	16bit	16bit
Power Consumption(avg.)	250w/m²	250w/m²	250w/m²	250w/m²
Input Voltage	AC110/220±10% ,50~60Hz	AC110/220±10%, 50~60Hz	AC110/220±10%, 50~60Hz	AC110/220±10%, 50~60Hz
Temperature(operating/storage)	-20~50°C / -40~60°C	-20~50°C / -40~60°C	-20~50°C / -40~60°C	-20~50°C / -40~60°C
Humidity(operating/storage)	10%~90%RH / 10%~85%RH	10%~90%RH / 10%~85%RH	10%~90%RH / 10%~85%RH	10%~90%RH / 10%~85%RH
MTBF	≥1000hrs	≥1000hrs	≥1000hrs	≥1000hrs
Life Span	≥100000hrs	≥100000hrs	≥100000hrs	≥100000hrs
Pixel Failure	<0.0003	<0.0003	<0.0003	<0.0003
