P2.97mm Indoor LED Display Video Wall for Rental

P2.97mm Indoor LED Display Video Wall for Rental

Get Latest Price

Payment Type:: L/C, T/T, Western Union

Incoterm:: FOB, CFR, CIF, EXW

Min. Order:: 1 Square Meter

Min. Order:: 1 Square Meter

Delivery Time:: 20 Days

Transportation:: Ocean, Air

Port:: Shenzhen

Quantity:

Your message must be between 20 to 2000 characters

Contact Now

Basic Info

Place of Origin:	China
Productivity:	8000 M²/month
Supply Ability:	10000 M²/month
Payment Type:	L/C,T/T,Western Union
Incoterm:	FOB,CFR,CIF,EXW
Certificate:	CCC.CE.ETL.FCC
Transportation:	Ocean,Air
Port:	Shenzhen

Product Description

P2.97mm Indoor LED Display Video Wall for Rental

BIR-I Serise
One Chassis,
Various Module Options

Specification

	BIR-I-2	BIR-I-3	BIR-I-4	BIR-I-6
Physical Pitch	2.97 mm	3.91 mm	4.81 mm	6.25 mm
Pixel Configuration	SMD 2121	SMD 2121	SMD 2020	SMD 3528
Pixel Density	112,896 pixels/m²	65,536 pixels/m²	43,264 pixels/m²	25,600 pixels/m²
Module Dimensions (W × H) (mm)	250 ×250 / 250 × 500	250 ×250 / 250 × 500	250 ×250 / 250 × 500	250 ×250 / 250 × 500
Panel Dimensions (mm)	500 × 500 × 80 / 500 × 1000 × 80	500 × 500 × 80 / 500 × 1000 × 80	500 × 500 × 80 / 500 × 1000 × 80	500 × 500 × 80 / 500 × 1000 × 80
NO .of Modules Per Panel (W × H)	2 × 2	2 × 2	2 × 2	2 × 2
Physical Resolution of Module (W × H)	84 × 84 / 84 × 168	84 × 84 / 84 × 168	84 × 84 / 84 × 168	84 × 84 / 84 × 168
Physical Resolution of Panel (W × H)	168 × 168 / 168 × 336	128 × 128 / 128 × 256	104 × 104 / 104 × 208	80 × 80 / 80 × 160
Single Cabinet Weight	7 / 13 kg/panel	7 / 13 kg/panel	7 / 13 kg/panel	7 / 13 kg/panel
Processing	16 bit	16 bit	16 bit	16 bit
Colours	281 trillion	281 trillion	281 trillion	281 trillion
Contrast Ratio	4,000 : 1	4,000 : 1	4,000 : 1	4,000 : 1
Average Power Consumption	60 /120 W /panel	60 /120 W /panel	60 /120 W /panel	60 /120 W /panel
Max Power Consumption	110 /400 W/panel	110 /400 W/panel	110 /400 W/panel	110 /400 W/panel
Operating Temp/Humidity	-10ºC - 60ºC / 10% - 60%	-10ºC - 60ºC / 10% - 60%	-10ºC - 60ºC / 10% - 60%	-10ºC - 60ºC / 10% - 60%
Storage Temp/Humidity	-30ºC - 60ºC / 10% - 60%	-30ºC - 60ºC / 10% - 60%	-30ºC - 60ºC / 10% - 60%	-30ºC - 60ºC / 10% - 60%
Brightness	900 - 1,200nits	900 - 1,200nits	900 - 1,200nits	900 - 1,200nits
Horizontal Viewing Angle	160°	160°	160°	160°
Vertical Viewing angle	140°	140°	140°	140°
Expected Lifetime	100, 000 Hrs	100, 000 Hrs	100, 000 Hrs	100, 000 Hrs
Max Stacking	20/10	20/10	20/10	20/10
Max Hanging	20/10	20/10	20/10	20/10
Servicing	Front / Rear	Front / Rear	Front / Rear	Front / Rear
IP Rating (Front/Rear)	IP 40 / IP 21	IP 40 / IP 21	IP 40 / IP 21	IP 40 / IP 21

Feature

Unsurpassed Color Uniformity
→ Unique color calibration process
→ Tight bin selection for LED wavelength
→ Deep black levels,contrast ratio 4000:1

LED Screen

Fast Installation and Easy Maintenance
→ Truss hanging and ground support both available
→ Cable-less between modules
→ Front and rear access
→ Tools free installation
