P1.92 280 Trillion Colour Indoor Fixed LED Display
  • P1.92 280 Trillion Colour Indoor Fixed LED Display
  • P1.92 280 Trillion Colour Indoor Fixed LED Display
  • P1.92 280 Trillion Colour Indoor Fixed LED Display
P1.92 280 Trillion Colour Indoor Fixed LED Display
P1.92 280 Trillion Colour Indoor Fixed LED Display
P1.92 280 Trillion Colour Indoor Fixed LED Display

P1.92 280 Trillion Colour Indoor Fixed LED Display

Payment Type:
L/C, T/T
Incoterm:
FOB, CFR, CIF, FCA, CPT
Min. Order:
1 Piece/Pieces
Min. Order:
1 Piece/Pieces
Delivery Time:
30 Days
Transportation:
Ocean, Land, Air
Port:
Shenzhen, Guangzhou
Quantity:

Your message must be between 20 to 2000 characters

Contact Now
Basic Info
Basic Info
Place of Origin: China
Productivity: 6000 ㎡/ Month
Supply Ability: 6000 ㎡/ Month
Payment Type: L/C,T/T
Incoterm: FOB,CFR,CIF,FCA,CPT
Certificate: CCC,FCC,ETL,CE,EMC,RoHS
HS Code: 8528591090
Transportation: Ocean,Land,Air
Port: Shenzhen,Guangzhou
Product Description
Product Description


P1.92 280 Trillion Colour Indoor Fixed LED Display



Description

1. High refresh, high gray level, high resolution and high contrast, coupled with the industry's advanced point-by-point correction technology, making the display more gorgeous and vivid.



2. With high contrast, consistent white balance, uniform display color, high-definition screen, can meet the requirements of the scene



3. Frequent video source switching and powerful seamless switching system.



4. Not only easy to install and disassemble, but also has the cost advantage of making a large stage background



5. With professional audio and video processing systems, support real-time, large and clear real-time images, break seat limits, make remote viewing performance easier, and bring an immersive audio-visual feast. Wonderful scenes, slow motion playback, close-ups, create a special background environment.


Fine Pitch LED Videowall

Small Pitch Indoor LED Panel

indoor led videowall

Indoor LED Display


Advantage

1.High-quality high-brightness LED dot matrix module, coated with ink color, not easy to damage, ensuring the best viewing angle



2.Constant voltage chip driver reduces power consumption and improves stability. Simple modular design with low cost and easy maintenance



3.Can perform single point, single lamp maintenance and low cost.



4.The shape is clean, light weight, small size, safe 5V low voltage power supply system, making the module more attractive.


5. In addition, the high-definition effect has a uniform brightness, and the soft color is suitable for close observation of the indoor range.


Physical Pitch

1.92mm

Pixel Configuration

SMD 1010

Pixel Density

270,000pixels/m²

Module Dimensions (W × H) (mm)

200 × 300

Panel Dimensions (mm)

400 × 300

NO. of Modules Per Panel (W × H)

2 × 1

Physical Resolution of Module (W × H)

208 × 156

Physical Resolution of Panel (W × H)

208 × 156

Panel Material

die-casting

Single Cabinet Weight

4.6 kg/panel

Processing

16 bit

Colours

281 trillion

Contrast Ratio

4,000 :1

Average Power Consumption

220 w/m²

Max Power Consumption

800 w/m²

Driving Method

1/26Scan

Brightness

>800 nits

Refresh Rate

≥1,500 Hz

Horizontal Viewing Angle

140°

Vertical Viewing angle

140°

Expected Lifetime

≥50,000 Hrs

Operating Temp/Humidity

-20°C - 50 °C / 10% - 90%

Storage Temp/Humidity

-40°C - 60°C / 10% - 85%

Max Stacking

20 panels

Max Hanging

16 panels

Servicing

Front / Back

IP Rating (Front/Rear)

IP 30

Certification

CCC,TUV-CE,ETL
