High Refresh Rate Fixed LED Display

Get Latest Price

Payment Type:: L/C, T/T, D/P

Incoterm:: FOB, CFR, CIF, FCA, CPT

Min. Order:: 1 Piece/Pieces

Min. Order:: 1 Piece/Pieces

Delivery Time:: 30 Days

Transportation:: Ocean, Land, Air

Port:: Shenzhen, Guangzhou

Quantity:

Your message must be between 20 to 2000 characters

Contact Now

Basic Info

Place of Origin:	China
Productivity:	6000m²/month
Supply Ability:	6000m²/month
Payment Type:	L/C,T/T,D/P
Incoterm:	FOB,CFR,CIF,FCA,CPT
Certificate:	CCC,CE,ETL,FCC,EMC,Rohs
HS Code:	8528591090
Transportation:	Ocean,Land,Air
Port:	Shenzhen,Guangzhou

Product Description

BAKO VISION is one-stop solution provider for projection and LED diplay.UHD Series is really adjust to the indoor fixed LED display,which can present a great image.

Application

Control Room,Meeting Room,Airport,Fashion Store,TV Studio,Restaurant,Monitor Center,Video Conference,Opera House.

Features

Complete LED Display Solution

Design,supplied and supported as a single solution.BAKO VISION LED Display include

everything you need - from cable to preconfigured processors.This ensures a hasle-free

set-up for truly seamelss installation.

Indoor Fixed LED Display

Easy installation and maintenance

UHD Series can be mouted directly on to the surface of a suitable

Wall without requiring a mounting free .Front access enables a fast

simple low-cost installation and easy maintennace.

Fine Pitch LED Display

Reliability

Design and built for outstanding reliability,aging test for at least 72 hours.

UHD series combine superior image processing technology with exceptional

engineering and premium quality components to provide ultimate peace of mind.

Indoor Fixed LED display

Parameter

Model	UHD-1.6
Pixel Pitch	1.66 mm
Pixel Density	360,000 pixels/m²
LED Type	SMD1010
LED Configuration	1R1G1B
Cabinet Dimension	400 × 300 mm
Cabinet Resolution	240 × 180
Cabinet Weight	4.6kg
Cabinet Material	die-casting
Ingress Protection (front/rear)	IP40/IP21
Brightness	>800nits
Viewing Angle(H/V)	140°/140°
Driving Method	1/30 Scan
Power Consumption(avg.)	220w/m²
Frame Refresh	≥ 60Hz
Data Refresh Rate	≥ 1500Hz
Gray Scale	16bit
Power Supply	AC 110/220±10% 50~60Hz
Temperature (operating/storage)	-20~50°C -40~60°C
Humidity(operating/storage)	10%~90%RH 10%~85%RH
Life Span	≥50000 Hours
Pixel Failure	<0.0003
Max stacking	20
Max Hanging	20

FAQ

1.What is LED?
LED is sanded for light emitting diode, a kind of semiconductor which is used to give and receive the electronic signal into infrared rays or light, using the characteristics of compound semiconductor. This is used for household appliances, remote controller, electric bulletin board, various kinds of automation appliances.
2. What are pixel pitch, pixel density, LED QTY and pixel configuration?
Pixel pitch is the distance between neighboring pixels.
Pixel density is the quantity of pixels per square meter.
LED qty is the quantity of LED lamps per square.
Pixel configuration is the description of the consistence of a pixel, for instance, we use 1 red lamp, 1 green lamp, and 1 blue lamp to compose a pixel, the pixel configuration is 1R1G1B.
3. What are LED type, module size and module resolution?
LED type is the description of LED lamp, for instance, the brand, the shape in physical, the size of the lamp
Module size is the measurement of a module.
Module resolution is the number of pixels per module.
