What is High Tg Circuit Boards (High TG printed circuit board) ?

Tg means Glass Transition Temperature.FR4 is a code name for a grade of Epoxy Glass material. The higher Tg, the better performance of PCB heat resistance, moisture resistance, chemical resistance, stability, and other characteristics. General fr4 Tg is 130-140 centigrade, moderate Tg is greater than 150-160 centigrade, High-Tg is greater than 170 degrees.

As usual, made with Tg ≥ 170℃ PCB material, which is called high Tg printed circuit board. With the rapid development of the electronics industry, high Tg material is widely used in computer, communication equipment, precise apparatus and instrument and etc.

FR4 material can often provide the best solution

The glass transition temperature of PCB, referred to as "Tg", indicates the point at which the PCB material will begin to transform. If the operating temperature exceeds the designated Tg value, the board will begin to change from a solid to a liquid state, which is likely to have an adverse effect on its ability to function.

Standard PCBs are manufactured with materials offering a TG value of 140°C, which can withstand an operating temperate of 110°C. While this may not be suitable for extreme-temperature processes that are commonplace in applications such as automotive, industrial or high-temperature electronics. In these situations, a PCB made from FR-4 material can often provide the best solution.

What Is FR4?

FR-4 is a grade designation for flame-retardant fiberglass reinforced epoxy material. Thus, FR-4 PCB offers a much greater level of resistance to heat than a standard PCB. FR-4 circuit boards are divided into four classifications that are determined by the number of copper trace layers found in the material:

• Single-sided PCB / Single-layer PCB
• Double-sided PCB / Double-layer PCB
• Four or more than 10 layers PCB / Multilayer PCB

Providing the Right High-Temperature PCB for Your Applications

JHYPCB offers a wide selection of high-temperature PCB products manufacturing services either with FR-4 or other high-quality heat- and temperature-resistant Tg materials. We are able to perform high-temperature PCB fabrication for automotive, industry and high-temperature electronics applications. We can manufacture High-Tg PCBs with a Tg value of up to 180°C.

Selection of high temperature PCB materials

Learn more about JHY PCB by exploring the manufacturing capability of High TG PCB below. We can do more than you can imagine.
