Outdoor rental LED video wall panel display
Quantity:
Your message must be between 20 to 2000 characters
Contact NowBasic Info
Basic Info
Product Description
Product Description
Product Description
|
Pixel Pitch
|
3.91mm
|
4.81mm
|
5.95mm
|
|
Pixel Resolution
|
65,536dots/m²
|
43,264dots/m²
|
28,224dots/m²
|
|
Module Resolution
|
(W)64 x (H)64pixels
|
(W)52 x (H)52 pixels
|
(W)42 x (H)42 pixels
|
|
Module Size
|
(W)250mm x (H)250mm
|
(W)250mm x (H)250mm
|
(W)250mm x (H)250mm
|
|
Module Weight
|
Around 720g
|
Around 720g
|
Around 720g
|
|
Driver Mode
|
Current Driving
|
Current Driving
|
Current Driving
|
|
Scan Mode
|
1/32S
|
1/13S
|
1/7S
|
|
Operation Voltage
|
DC5V±10%
|
DC5V±10%
|
DC5V±10%
|
|
Max Module Current
|
Around 8A(typical)
|
Around 7.5A(typical)
|
Around 8A(typical)
|
|
Max Power Consumption
|
Around 40W(typical)
|
Around 37.5W(typical)
|
Around 40W(typical)
|
|
Power Interface
|
VH4
|
VH4
|
VH4
|
|
Signal Interface
|
HUB75D (IDC16)
|
HUB75D (IDC16)
|
HUB75D (IDC16)
|
|
Max Brightness
|
6500cd/m²
|
6500cd/m²
|
6500cd/m²
|
|
Color Temperature
|
9500K
|
9500K
|
9500K
|
|
Viewing Angle(H/V)
|
120°/120°
|
120°/120°
|
120°/120°
|
|
Best Viewing Distance
|
4-40m
|
5-50m
|
6-60m
|
|
Grey Level
|
14bits
|
14bits
|
14bits
|
|
Brightness Calibration
|
supported
|
supported
|
supported
|
|
Refresh Rate
|
≥1920Hz
|
≥1920Hz
|
≥1920Hz
|
|
Brightness Adjust Rang
|
0 to 255 adjustable
|
0 to 255 adjustable
|
0 to 255 adjustable
|
|
Life Span
|
50,000 Hour
|
50,000 Hour
|
50,000 Hour
|
|
Operation Temperature
|
-20 ℃ ~ 60 ℃
|
-20 ℃ ~ 60 ℃
|
-20 ℃ ~ 60 ℃
|
|
Operation Humidity
|
10%-90%RH without condensation
|
10%-90%RH without condensation
|
10%-90%RH without condensation
|
|
Stock Temperature
|
-40 ℃ ~ 80 ℃
|
-40 ℃ ~ 80 ℃
|
-40 ℃ ~ 80
|
About Joyled
Shenzhen Joy LED Display Co., Ltd. is a LED electronic display and LED lighting application products. It is invested by three senior LED industry professionals in China. It integrates R&D, production, sales, engineering, and after-sales services. High-tech companies, adhering to the unique advantages in the field of LED display and control, the company has fullyintroduced the ISO9000 series quality management system, the production process in strict accordance with the requirements of RoHS and CE directives pay attention to every job details in the manufacturing process management Lean management, strive for perfection, is a medium-sized enterprise producing high-tech electronic display products.
