MICRO USB WITH 4 SHELL DIP REVERSE

Get Latest Price

Payment Type:: T/T, Paypal, Western Union

Incoterm:: FOB, CIF, EXW, FCA

Min. Order:: 1000 Bag/Bags

Min. Order:: 1000 Bag/Bags

Delivery Time:: 10 Days

Transportation:: Ocean, Air

Port:: SHENZHEN, SHENZHEN

Quantity:

Your message must be between 20 to 2000 characters

Contact Now

Basic Info

Place of Origin:	China
Productivity:	100000K/month
Supply Ability:	100000K/month
Payment Type:	T/T,Paypal,Western Union
Incoterm:	FOB,CIF,EXW,FCA
Certificate:	ISO9001
HS Code:	8536909000
Transportation:	Ocean,Air
Port:	SHENZHEN,SHENZHEN

Product Description

MICRO USB 5P AB Type RECAPTACLE, EJECTOR TYPE WITH 4 SHELL DIP 8.35mm x 4.45mm,REVERSE TYPE

Note:
1.Material:
1.1 Housing: High temperature thermoplastic
with g.f,UL94v-0
1.2 Contact: copper alloy,t=0.20mm
1.3 Shell: copper alloy&SUS
2.Specification:
2.1 Current rating: 1 A Max.
2.2 Dielectric withstanding
voltage: 100 V(ac) for 1 min.
2.3 Contact resistance: 30 mW Max.
2.4 Insulation resistance: 100 MW Min.
2.5 Total mating force: 3.57 Kgf Max.
2.6 Total unmating force: 1.0 Kgf Min.0.81~2.05
Kgf Min.after 10000 insertion/extration cycles
2.7 Temperature range: -30°C~80°C

MUFM21 21-MICRO USB 5P AB RECAPTACLE, EJECTOR TYPE WITH 4 SHELL DIP,REVERSE TYPE
