0.5mm FPC Verticial SMT Bottom Contact Connector

$500.00

≥1000 Bag/Bags

Min. Order:: 1000 Bag/Bags

Min. Order:: 1000 Bag/Bags

Transportation:: Ocean, Air, Express

Port:: SHENZHEN

Quantity:

Your message must be between 20 to 2000 characters

Contact Now

Basic Info

Place of Origin:	China
Productivity:	100000K/month
Supply Ability:	100000K/month
Payment Type:	T/T,Paypal
Incoterm:	FOB,CIF,EXW,FCA
Certificate:	ISO9001
HS Code:	8536909000
Transportation:	Ocean,Air,Express
Port:	SHENZHEN,

Product Description

0.5mm FPC,Verticial SMT,Bottom Contact

MATERIAL
HOUSING:HIGH-TEMP.
ACTUAOR:HIGH-TEMP.
CONTACT:COPPER ALLOY.PLATING:ALL TIN OR GOLD.
HOLDDOWN:COPPER ALLOY.PLATING:ALL TIN,LEAD FREE.

ELECTRICAL
VOLTAGE: 50V MAX.
CURRENT: 0.5A MAX.
DIELECTRIC WITHSTANDING VOLTAGE: 250 VAG.
INSULATION RESISTANCE: 50 MEGAOHMS MIN.
CONTACT RESISTANCE: 20 MILLIOHMS MAX.

ENVIRONMENTAL
TEMPERATURE RANGE: -20°C TO 85°C.

FEATURE AND SPECIFICATIONS
SIZES 03 TO 61 PIN.
FOR 0.3mm THICKNESS FFC/FPC.
0.5mm FPC,VERTICIAL SMT,Bottom Contact FPC0.5-XXXXXXXXX11
