2.54mm Pitch Box Header Connector Straight

Get Latest Price

Payment Type:: T/T, Paypal, Western Union

Incoterm:: FOB, CIF, EXW, FCA

Min. Order:: 1000 Bag/Bags

Min. Order:: 1000 Bag/Bags

Delivery Time:: 10 Days

Transportation:: Ocean, Air

Port:: SHENZHEN, SHENZHEN

Quantity:

Your message must be between 20 to 2000 characters

Contact Now

Basic Info

Place of Origin:	China
Productivity:	100000K/month
Supply Ability:	100000K/month
Payment Type:	T/T,Paypal,Western Union
Incoterm:	FOB,CIF,EXW,FCA
Certificate:	ISO9001
HS Code:	8536909000
Transportation:	Ocean,Air
Port:	SHENZHEN,SHENZHEN

Product Description

Shenzhen Antenk Electronics Co., Ltd. launched a 2.54mm Box Header 180° H=9.00mm Electronics ,The simple cow is usually composed of a square plastic socket and a number of square needles arranged neatly. The difference between the simple cow connector and the horn connector is that the simple horn removes the buckles on both sides.

According to the requirements, the outer dimensions of the simple cattle connector are commonly used in 1.27 pitch, 2.0 pitch, and 2.54 pitch; according to the spacing, the diameter of the square pin used is also changed accordingly. The bottom and PCB contact surface can be designed as SMT patch or DIP in-line 180 degrees.

SPECIFICATION
Current Rating: 3.0Amp
Insulation Resistance: 1000MΩ min
Contact Resistance: 10MΩ max
Withstand Voltage: 500V AC/DC
Operating Temperature: -55°C to +125°C
MATERIAL
Housing: PBT.Glass filled UL94V-0
Contact Material: Brass
Contact Plating:
T=Tin plated on all area,ni under plated all over.
G=Gold plated on all area,ni under plated all over.
L=0.4u"(Gold)
N=3u"(Gold)

BHDS09 2.54mm Box Header 180° H=9.00
