Product Description

7.62MM 2P Power+20P Signal Male Straight Dip Power Connector

1.Material:
A.Terminal:Phosphor Copper C5191
B.Housing:PA9T+30% G/F UL94V-0 Color: Black
2.Plating:
Signal Contact: 30u-50u Nickel Plated, 1U Gold Plated
Power Contact: 30u-50u Nickel Plated, 1U Gold Plated3.
3.Electrical Performance Requirements:
Rated Voltage: Signal Contact: 60V; Power Contact: 250V
Rated Current: Single Power Contact Max 40A; All Power Contacts
Max 1.5A; Single Signal Contact Max 3A; All Signal Contacts Max 1.5A
Withstand Voltage:Leakage Current: Contact Voltage: 1000 VDC Less
Than 1 mA / Min, Between Power Contacts and Between Power and Signal
Contacts:2500Vdc / Min, Leakage Current Less Than 1mA
Insulation resistance: Between Signal Contacts: 500MΩ;
Between Power Contacts: 500M Ω
And Signal Contact: 10000M Ω
Working Temperature: -40~+125℃(Including The Temperature Rise of 40 ℃);
