Modular Jack 8P8C 1x4P with Shielded

Modular Jack Top entry 8P8C 1x4P Shielded With LED,Slim 13.20mm type

Specifications:

1.Electronical Characteristics:
 1.1 Voltage Rating:1000 VAC 1 Minute
 1.2 Current Rating:1.5A
 1.3 Contact Resistance:50 Milliohms Maximum
 1.4 Insulation Resistance:500 Megohms Min
 1.5 Dielectric Strength:1000 VAC RMS 60HZ.1MIN.
2.Mechanical Characteristics:
 2.1 Operating Life:750 Cycles Minimum
 2.2 PCB Retention Pre-solder:1 LBS Minimum
 2.3 PCB Retention Post-solder:10 LBS Minimum
3.Material & Plating
 3.1 Housing Material:High Temp.Plastic UL94V-0
 3.2 Contact Material:Phosphor Bronze,T=0.35mm
 3.3 Plating:Gold Plating Over Nickel
4.Environmental:
 4.1 Storage:-40°To +85°
 4.2 Operation:-40°To +85°
 4.3 Wave Soldering Temperature:230°To 250° (3-5 Seconds)
