Rj45 jack top entry 6p6c

$500.00

≥1000 Piece/Pieces

Min. Order:: 1000 Piece/Pieces

Min. Order:: 1000 Piece/Pieces

Transportation:: Ocean, Air, Express

Port:: ShenZhen

Quantity:

Your message must be between 20 to 2000 characters

Contact Now

Basic Info

Place of Origin:	China
Productivity:	2000K/month
Supply Ability:	2000K/month
Payment Type:	T/T,Paypal
Incoterm:	FOB,CFR,EXW,FCA
Certificate:	ISO9001
HS Code:	8536909000
Transportation:	Ocean,Air,Express
Port:	ShenZhen,

Product Description

Rj45 jack top entry 6p6c full plastic wıthout panel

Specifications

MATERIAL:
1.HOUSING MATERIAL :GLASS FILLED POYESTER UL94V-0.
2.CONTACT MATERIAL :PHOSPHOR BRONZE t=0.3mm
3.PLATING:SELECTING GOLD PLATING 1μ~50μ"OVER
NICKEL IN CONTACT AREA.150μ" TIN
PLATIN.OVER NICKEL IN SOLDER AREA
4.SHIELD :0.2mmTHICKNESS COPPER WITH NICKEL PLATEI
ELECTRICAL
1.VOLTAGE RATING :125VAC RMS
2.CURRENT RATING :1.5AMP
3.CONTACT RESISTANCE:30MILLIOHMS MAX
4.INSULATION RESISTANCE 500MEGOHMS MIN @500V DC
5.DIELECTRIC WITHSTANDING RESISTANCE
:1000V AC RMS 50Hz. 1MIN
MECHANICAL
1.DURRABILITY :750 CYCLES MIN
2.PCB RETENTTON PRB-SOLDER :1 LB MIN
REVIRONMENTAL
1.STORAGE :-40°C TO 85°C
2.OPERATION :0°C TO 70°C
