Insulating Glass Desiccants with Dia: 0.5-0.9mm 1.5~2.0mm

Insulating Glass Desiccants with Dia: 0.5-0.9mm 1.5~2.0mm

Get Latest Price

Payment Type:: L/C, T/T, D/P, Western Union

Quantity:

Your message must be between 20 to 2000 characters

Contact Now

Basic Info

Place of Origin:	China
Productivity:	5000 Metric Tons / Year.
Supply Ability:	5000 Metric Tons / Year.
Payment Type:	L/C, T/T, D/P, Western Union

Product Description

Model NO.: 0.5-0.9mm 1.0-1.5mm 1.5-2.0mm

Certificate: ISO9001: 2000

Type: Ig Desiccant

Trademark: JINCHENG

Transport Package: by Carton Box, Each Box 25kgs Net.

Specification: 0.5-1.0mm, 1.0-1.5mm, 1.5-2.0mm

Origin: China

HS Code: 3824999990

Insulating glass molecular sieve is the product to provide the insulating glass industry with the highest water capacity and lowest gas adsorption for solvent-free systems.

Feature
Very Selective Adsorption
Insulating glass molecular sieve has been designed as a high water capacity adsorbent with the lowest capacity for air or other gases. The highly selective pore structure of assures excellent water dew point protection while eliminating the co-adsorption of gases in the sealed air space.

Low Deflection
Because insulating glass molecular sieve minimizes pick up of other gases, it reduces adsorbent contribution unit deflection and stress under severe climatic conditions.

Economy and Performance
It increases gas-filled nit production rates since units can be sealed immediately after filling. In addition, the use of insulating glass molecular sieve maintains unit sound and heating insulation values by minimizing the adsorption of gases from the sealed space.

Homogeneous and Non-Separating
Unlike blends of two different desiccants that separate because of different component densities, insulating glass molecular sieve is homogeneous and uniform. Each bead is like every other. Theres no need to worry about unit-to-unit variation, which can occur with blends.

Residual Moisture
Insulating glass molecular sieve is supplied as a fully activated Insulating Glass Adsorbent, ready for use in spacer filling operations.

Technical Parameter
Item	Unit	Technical data
Shape		Sphere
Diameter	mm	0.5-1.0	1.0-1.5	1.5-2.0
Pore Volume	Å	3	3	3
Bulk density	g/ml	0.74-0.80	0.72-0.78	0.72-0.78
Static water adsorption	%	≥20.0	≥20.0	≥20.0
Crushing strength	N/piece	≥5	≥15	≥20
Dust (Turbidity meter)	ppm	≤30	≤30	≤30
Delta T (10 g/10ml)	Degree C	≥38	≥38	≥38
Equilibrium N2 capacity	%	≤0.2	≤0.2	≤0.2
Dew point	Degree C	<-73	<-73	<-73
Size ratio	%	≥98.0	≥98.0	≥98.0
Water content, as shipped	%	<1.5	<1.5	<1.5
