10G SFP+ AOC active optical cable

10G SFP+ Active Optical Cable (AOC) is part of a family of SFP+ products to serve 10Gb Ethernet (10GbE) applications. The letters [xx" of the part number AFBR-2CARxxZ denoted the cable length in meters.
The 10G  SFP+AOC enables 10GbE equipment designs with very high port density based on the new electrical and mechanical specification enhancements to the well-known SFP specifications developed by the SFF Committee. The specifications are referred to as [SFP+" to represent the enhancements over previous SFP specifications. The SFP+ AOC have a cable length up to 20m. These AOCs can be used as an alternative solution to SFP+ passive and active copper cables, while providing improved signal integrity, longer distances, superior electromagnetic immunity and better bit error rate performance.

Features:
 Compliant to SFP+ Electrical MSA SFF-8431
 Compliant to SFP+ Mechanical MSA SFF-8432
 Multi rate of up to 11.3Gbps
 Electrical interface compliant to SFF-8431
 Hot Pluggable
 850nm VCSEL transmitter, PIN photo-detector receiver
 Up to 300m on OM3 MMF
 Operating case temperature: 0 to 70℃
 All-metal housing for superior EMI performance

Applications
 10 Gigabit Ethernet
 4G and 8G Fibre Channel Applications
 1x InfiniBand QDR. DDR, SDR
 High-performance computing clusters
 Servers, switches, storage and host card adapters

Recommended operating Conditions
