Heated Insoles Battery Power Bank 3.7v 2300mAh (BP3502)
- Payment Type:
- T/T, Paypal, Western Union
- Incoterm:
- FOB
- Delivery Time:
- 30 Days
- Transportation:
- Ocean, Air
- Port:
- Shenzhen, Hongkong
Your message must be between 20 to 2000 characters
Contact Now| Place of Origin: | China |
|---|---|
| Payment Type: | T/T,Paypal,Western Union |
| Incoterm: | FOB |
| HS Code: | 85076000 |
| Transportation: | Ocean,Air |
| Port: | Shenzhen,Hongkong |
The BP3502PC-3V2300 is 3.7v 2300mAh version of BP3502 li ion rechargeable battery pack made of 1pcs Panasonic 103450 battery or other optional 103450 battery, The BP3502PC battery is a Pulse DC output battery with adjustable output settings. The BP3502 battery is the battery for Volt 3V Rechargeable Battery Heated Sock Liner. The battery comes with a built-in microprocessor controller with 4 power level settings on non-wireless verison or 3 setting for wireless version. On the highest setting, the socks will provide over 3 hours of soothing warmth to the bottom of the foot, from the toes to your heel. Application: heated foot warmer, battery socks, electric heated socks, battery powered socks, heated gloves and socks, mens warm slippers, rechargeable heated socks, rechargeable heater, electric feet warmers and other 3v heated wear products.
Battery ID: BP3502PC-3V2300
Cell inside: 1pcs li ion 103450 battery
Dimension: 14*56*56mm
Capacity: 3.7v 2300mAh
Input: 4.2v 1.5A max
Output: 4.2v~3V 2A max, PWM Pulse DC output with adjustable output setting,
3 levels by wireless or 4 levels no wireless or other specified settings.
Input/Ouput Terminal: 3.5*1.35mm coax type,
or designated connector in extension cable.
Weight: 55g
Function Code: PC (CC, DM model also available for this battery)
The BP3502 battery is designed for light duty electric heated wears application. It has most compact size 14*56*56mm , a 3.5*1.35mm coax type socket connector or other specified connector type.
The BP3502 battery LED light can be made to reflect the battery fuel level status by lighting up different color.
The BP3502 battery can be made to have different output mode: Constant DC type, Pulse DC type (adjustable pulse settings), or two both. Asarke Heated Clothing Battery is using Pulse-Width Modulation(PWM) or Pulse-Duration Modulation (PDM) technology which able to control/adjust the output power rate thus achieve desirable heat level in heater. Pulsed DC (PDC) or pulsating direct current is a periodic current which changes in value but never changes direction, pulsating direct current is used on PWM controllers.
Typical Capacity Option:
3.7v 1800mAh/1900mAh/2000mAh/2300mAh
We make li ion battery packs for all heated wears in all size option, search (model number) to find more information in our site.
