Samsung ICR18650-32E Battery 3200mAh

The Samsung ICR18650-32E cell is top high capacity 18650 battery cells for wide application with 3200mAh capacity and 6.4A Max. Discharge Current, and doing good at keeping high output voltage, even when loaded.

Nominal Specifications

• Typical Capacity: 3,200mAh (0.2C, 2.50V discharge)
• Minimum Capacity: 3,100mAh (0.2C, 2.50V discharge)
• Charging Voltage: 4.2V
• Nominal Voltage: 3.65V (0.2C discharge)
• Charging Method: CC-CV (constant voltage with limited current)
• Charging Current Standard charge: 960mA
• Charging Time Standard charge: 5hours
• Max. Charge Current: 3,200mA (not for cycle life)
• Max. Discharge Current: 6,400mA (for continuous discharge), 9,600mA (not for continuous discharge)
• Discharge Cut-off Voltage: 2.50V
• Cycle life: 500 cycles to 70% with 3200mA discharge, 300 cycles with 6200mA discharge.
• Cell Weight: 50g max
• Cell Dimension: Height : 65.2mm max, Diameter(max.) : Ø 18.50 mm
• Operating Temperature (Cell Surface Temperature): Charge : 0 to 45°C, Discharge : -20 to 60°C
• Storage Temperature: 1 year : -20~25°C, 3 months : -20~45°C, 1 month : -20~60°C

lygte-info Capacity Testing
