Samsung INR18650-25R 20A discharge battery cell

The Samsung InR18650-25r cell is top 20A discharge 18650 battery cells for EV application.  It is able to handle 20A continuous discharge.

Nominal Specifications

• Nominal discharge capacity: 2,500mAh
• Nominal voltage: 3.6V
• Standard charge: CCCV, 1.25A, 4.20 ± 0.05 V, 100mA cut-off
• Rapid charge: CCCV, 4A, 4.20 ± 0.05 V, 100mA cut-off
• Charging time: Standard charge : 180min / 100mA cut-off
• Rapid charge: 60min (at 25°C) / 100mA cut-off
• Max. continuous discharge: 20A(at 25°C), 60% at 250 cycle
• Discharge cut-off voltage: 2.5V
• Cell weight: 45.0g max
• Cell dimension: Height : 64.85 ± 0.15mm, Diameter : 18.33 ± 0.07mm
• Operating temperature (surface temperature): Charge : 0 to 50°C (recommended recharge release < 45°C), Discharge: -20 to 75°C (recommended re-discharge release < 60°C)
• Storage temperature (Recovery 90% after storage): 1.5 year -30~25°C, 3 months -30~45°C, 1 month -30~60°C
