2*3*4mm Red Through-hole LED Gravestone LED

234mm Red Through-hole LED Gravestone LED

Get Latest Price

Min. Order:: 5000 Piece/Pieces

Min. Order:: 5000 Piece/Pieces

Transportation:: Ocean, Land, Air

Port:: SHENZHEN

Quantity:

Your message must be between 20 to 2000 characters

Contact Now

Basic Info

Place of Origin:	China
Productivity:	1000000000 pcs/week
Supply Ability:	7000000000 pcs/week
Payment Type:	T/T,Paypal
Incoterm:	FOB,EXW,FCA
Certificate:	GB/T19001-2008/ISO9001:2008
HS Code:	8541401000
Transportation:	Ocean,Land,Air
Port:	SHENZHEN

Product Description

- Rectangular RED Through-Hole LED -

6242FRC62D3L14

234FRD is solid state lamps within a radial lead rectangular epoxy package. A tinted, diffused epoxy provides high on-off contrast and a flat high intensity emitting surface. This range of LEDs offer an uniterrupted light output due to a borderless package design. we uses a double heterojunction (DH) absorbing substrate (AS) aluminum gallium arsenide (AlGaAs) red LED chip in a light red epoxy package. Together they produce a strong light output over a wide range of drive currents.Rectangulal red through-hole led uses a high efficiency red GaAsP on GaP LED chip in a light red epoxy package.The 234FYD provides a yellow GaAsP on GaP LED chip in a yellow epoxy package.The 234LGD provides a green GaP LED chip in a green epoxy package. Features of the 234FRD, 234FYD and 234LGD series:1. Rectangular light emitting surface;2.Flat high sterance emitting surface;3.Ideal for flush mounted panel indicators;4.Ideal for backlighting legends;5. Long life: solid state reliability;6. IC compatible / low current requirements;7.Visible Light LEDs.There have kinds of blue LED shape for your choose, for instance: 3mm round top blue LED, 5mm round top through-hole LED, 2835 blue SMD LED, 5730 Blue LED, rectangular blue LED with size like 2*3*4mm and 2*5*7mm ect. You can choose any one of them for your design. Blue rectangular LED are widely used for different kinds of electronic products or the LED indicator, LED backlight and it also work perfect for your DIY project. Do you need some RED LED? Contact us now!

234 rectangle RED LED

- Size: 2mm*3mm*4mm High

- Pin length: 17mm/19mm

- Color: Red LED

- Lens type: Red

- Chip brand:Epileds

- Different color are available

- Warranty: 5 Years

- Different wavelength are available

- RoHS, REACH, EN62471

- Uniform light output

- Low Power consumption

- Long life-solid state reliability

- Anti UV epoxy resin package

- High temperature resistance

- Dimension Parameters -

234mm LED

. All dimensions are in millimeters ; 2. Tolerance is ± 0.10 mm unless otherwise noted.

*This case are also available for UV LED, Yellow LED, White LED, blue through-hole LED, red through-hole LED, IR LED ect.*

- Emitting Color -

* Colors in the photo was took by camera, please take actual emitting color as standard.

- Electrical Parameters -

Parameter	Symbol	Rating
Power Dissipation	Pd	120mw
Pulse Forward Current	IFP	100mA
Forward Current	IF	60mA
Reverse Voltage	VR	5V
Junction Temperature	Tj	115°C
Operating Tempertature	Topr	-40 - +80°C
Storage Tempertature	Tstg	-40 - +100°C
Soldering Temperature	Tsol	260°C
Electro-Static-Discharge(HBM)	ESD	3000v
Warranty	Time	5Years
Antistatic bag	Piece	1000Bag
*Pulse Forward Current Condition:Duty 1% and Pulse Width=10us.
*Soldering Condition:Soldering condition must be completed with 3 seconds at 260°C

Parameter	Symbol	Min	Typ	Max	Unit	Test Condition
Forward Voltage	VF	1.8	2.0	2.4	V	IF=20mA
Luminous Intensity	IV		2.5	3.5	lm	IF=20mA
Luminous Intensity	IV	5		8	lm	IF=50mA
Peak Wavelength	λP		633		nm	IF=20mA
Dominant Wavelength	λd	620	625	630	nm	IF=20mA
Half Width	Dl		22		nm	IF=20mA
Viewing Half Angle	2q1/2		±60		deg	IF=20mA
Reverse Current	IR			5	uA	VR=5V
*Luminous Intensity is measured by ZWL600.
*2q1/2 is the off-axis angle at which the luminous intensity is half the axial luminous intensity.
*lD is derived from the CIE chromaticity diagram and represents the single wavelength which defines the color of the device.
