0.2W Cool White LED 6000-6500K 2016 SMT 60mA
  • 0.2W Cool White LED 6000-6500K 2016 SMT 60mA
  • 0.2W Cool White LED 6000-6500K 2016 SMT 60mA
  • 0.2W Cool White LED 6000-6500K 2016 SMT 60mA
  • 0.2W Cool White LED 6000-6500K 2016 SMT 60mA
  • 0.2W Cool White LED 6000-6500K 2016 SMT 60mA
0.2W Cool White LED 6000-6500K 2016 SMT 60mA
0.2W Cool White LED 6000-6500K 2016 SMT 60mA
0.2W Cool White LED 6000-6500K 2016 SMT 60mA
0.2W Cool White LED 6000-6500K 2016 SMT 60mA
0.2W Cool White LED 6000-6500K 2016 SMT 60mA

0.2W Cool White LED 6000-6500K 2016 SMT 60mA

Min. Order:
4000 Piece/Pieces
Min. Order:
4000 Piece/Pieces
Transportation:
Ocean, Land, Air, Express, Others
Port:
SHENZHEN
Quantity:

Your message must be between 20 to 2000 characters

Contact Now
Basic Info
Basic Info
Place of Origin: China
Productivity: 30000000
Supply Ability: 30000000/Month
Payment Type: T/T,Paypal,WU
Incoterm: FOB
Certificate: ISO:9001
HS Code: 8541410000
Transportation: Ocean,Land,Air,Express,Others
Port: SHENZHEN
Product Description
Product Description

Is 6000K bright enough?

For some project, people will need their LED Lamps to be extremely bright. For some project are not. In this case, for those project that needs extremely high lumen LED, we recommend the high power white led, like 1W or 3W high power LED. And there are also some other project need the SMD LED with very small size and high brightness, we recommend 2016 SMD LED. With the same material, cool white LED will have higher brightness than warm white LED. If you just looking for bright white LED, then 6000K-6500K color temperature will working good for you.

2016WC60K28L3W 0.2W Cool White LED 6000k 6500K 2016 SMT 60mA


Electrical Parameters:

Parameter

Symbol

Min

Type

Max

Unit

Test Condition

Forward Voltage

VF

2.8

-

3.2

V

IF=60mA

Luminous Flux

IV

24

-

28

lm

IF=60mA

Color temperature

CCT

6000                   6500

 K

IF=60mA

Viewing Half Angle

 2θ1/2


120



deg

IF=60mA

Reverse Current

IR



5

uA

VR=5V

*Luminous intensity is measured by ZWL600.

*λD is derived from the CIE chromaticity diagram and represents the single wavelength which defines the color of the device.


Size of 2016 SMD LED SMT:

Size of 2016WC60K28L3W 0.2W Cool White LED 6000k 6500K 2016 SMT 60mA

*UV LED, Red SMD LED, Yellow LED, Blue SMD LED are all available in this 2016 SMD LED size.*


Product Details:

99.99% purity gold wire;

Silver plated LED frame;

Famous branded chips;

High quality epoxy;
