When it comes to FR-4 high-TG PCBs, Topscom has the experience and quality products you need for your industry. If you work with printed circuit boards that you will be subjecting to high temperatures, you need to be sure those PCBs can take the heat.

At Topscom, our high-temperature PCB products can handle extreme PCB glass transition-temperature rates and retain their integrity, so you can use these high-TG FR-4 boards with confidence. We have a 99 percent plus customer satisfaction rate and are well known for our reliable, fast service as shown by our customer testimonials.

If you're not sure whether your particular operation requires FR-5 high-TG boards or how exactly a TG PCB works to protect your sensitive circuits during implementation, we're happy to tell you everything you need to know. Read on to gain a full understanding of just how a high-temperature PCB works and what it can do for you. Once you're satisfied that FR-4 high-TG boards are right for you, follow the steps at the bottom of this page to get free quote on high TG FR-4 boards from Topscom today.

High-TG PCB Advanced Circuits Specification

The glass transition temperature of a printed circuit board, referred to as "Tg", indicates the point at which the PCB material will begin to transform. If the operating temperature exceeds the designated Tg value, the board will begin to change from a solid to a liquid state, which is likely to have an adverse effect on its ability to function.

Standard PCBs are manufactured with materials offering a TG value of 140°C, which can withstand an operating temperate of 110°C. While this may not be suitable for extreme-temperature processes that are commonplace in applications such as automotive, industrial or high-temperature electronics. In these situations, a PCB made from FR-4 material can often provide the best solution.

What Is FR-4?

FR-4 is a grade designation for flame-retardant fiberglass reinforced epoxy material. Thus, FR-4 PCB offers a much greater level of resistance to heat than a standard PCB. FR-4 circuit boards are divided into four classifications that are determined by the number of copper trace layers found in the material:

• Single-sided PCB / Single-layer PCB

• Double-sided PCB / Double-layer PCB

• Four or more than 10 layers PCB / Multilayer PCB

Providing the Right High-Temperature PCB for Your Applications

Topscom offers a wide selection of high-temperature PCB products manufacturing services either with FR-4 or other high-quality heat- and temperature-resistant Tg materials. We are able to perform high-temperature PCB fabrication for automotive, industry and high-temperature electronics applications. We can manufacture High-Tg PCBs with a Tg value of up to 180°C. Following table lists some of our commonly used materials for High-Tg PCBs production.

Material  TG

(DSC, °C)  Td

(Wt, °C)    CTE-z

(ppm/°C)  Td260

(min)         Td288

(min)

S1141 (FR4)      175  300  55     8       /

S1000-2M (FR4)        180  345  45     60     20

IT180        180  345  45     60     20

Rogers 4350B  280  390  50     /        /

Regardless of the scope or complexity of your PCB application, we have the technical expertise to develop customized PC boards that meets your specific demands. Check our capabilities in here:

Feature    Capability

Quality Grade  Standard IPC 2

Number of Layers    2 - 40layers

Order Quantity         1pc - 10000+pcs

Build Time        2days - 5weeks

Material  S1141 (FR4), S1000-2M (FR4), IT180, Rogers 4350B

Board Size        Min 6mm x 6mm | Max 500mm x 900mm

Board Thickness       0.4mm - 6.5mm

Copper Weight (Finished)         0.5oz - 2.0oz

Min Tracing/Spacing         3mil/3mil

Solder Mask Sides    As per the file

Solder Mask Color   Green, White, Blue, Black, Red, Yellow

Silkscreen Sides        As per the file

Silkscreen Color        White, Black, Yellow

Surface Finish  HASL - Hot Air Solder Leveling

Lead Free HASL - RoHS

ENIG - Electroless Nickle/Immersion Gold - RoHS

Immersion Silver - RoHS

Immersion Tin - RoHS

OSP - Organic Solderability Preservatives - RoHS

Min Annular Ring     4mil

Min Drilling Hole Diameter      6mil

Other Techniques    Gold fingers

Blind/Buried Vias

Countersink Holes

Get Production Price of Your High-Tg PCBs

For your High-Tg PCB fabrication price, please send your PCB design files (Gerber format preferred | Preorder Checklist) along with quantity requirements to us using this page. We will inform the price very shortly. If your application requires a Tg value that is not listed in the above table, feel free to send us a message using this contact form. We will get back to you very soon.
