DC 12V 5V Desktop Switching Power Supply

CE FCC RoSH Certification 12V Switching Power Supply

This switching power supply is dual output ,ABS+PC Material,the switching adapter's output voltage is dc 12v 5v ,output voltage is 2a ,this ac power adapter have two years warranty and have high efficiency min 88% .our switching power supply's dc connector have 4 pin 6 pin or your request. this switching power adapter have Short Circuit Protection,Over Current Protection,Over Voltage Protection,Operating Temperature.

Product Description:

Part NO.: 12V 5V 2A

DC Voltage: 12V/5V

Rate Current: 2A

Current range:0~2A

Rate power: 34W

Voltage tolerance:±5%

Line Regulation:±1%

Load Regulation:±5%

AC Input:100~240Vac 50/60Hz max: 90~264Vac 47/63Hz

Efficiency:>88%

Short Circuit Protection: Shall be protected when any output operation in circuit shortcondition,and shall be auto restart

when  the fault condition is removed.

Over Current Protection:130%-150%

Over Voltage Protection:115%-135%

Operating Temperature:-10-50ºC (±10ºC)

Relative Humidity:20%-90% RH

Storage Temperature:-40-80ºC (±10ºC)

DC Connector:4PIN or 6PIN connector (Customized Available)

DC Cable:1.2m/1.5m/1.8m(Customized Available)

AC Cable:1.2m ac power cord with USA/UK/EU/AU/India plugs

Features:

• Universal AC input/Full range(up to 264Vac)
• Protection: Short circuit/Overload/Over temperature
• High efficiency, long life and hign reliaility
• 100% full load burn-in test
• Two years warranty
• Class 1 design
