Unmanaged PoE Auto-check switch
Overview
- NC2081PE is a 9-port PoE unmanaged switch that supports up to 8*10/100M PoE ports and 1*10/100M port. 8* 10/100M ports support PoE+, conforming to IEEE 802.3af/at standard, single port PoE power up to 30W, the maximum whole machine power is 120W.
- NC2081PE provides three modes, Extend, Default and VLAN, to adapt to various complex environments. At the same time, support PoE Auto-check function, which is specially designed to solve the problems of equipment frozen. It can automatically detect the frozen PD equipment and restart the ports’ output of PSE, and restart the PD device. It greatly reduces the maintenance difficulty of engineering.
- NC2081PE has a high anti-interference ability, the product supports 6KV surge protection, and 6KV contact / 8KV air ESD protection.
- NC2081PE supports wall hanging and desktop installation, reliable and durable, and can be used in security network video monitoring, network engineering and other occasions.
Specifications
|
Parameter |
Specifications |
|
Power supply |
Powered by power adaptor |
|
Range of voltage |
DC 48~57V |
|
Consumption |
Self consumption<5W, PoE output max. 120W |
|
Downlink ports |
Ports 1~8: 10/100Base-TX 30W PoE RJ45(IEEE 802.3af/at) |
|
Uplink ports |
Ports 9: 10/100Base-TX RJ45 |
|
PoE ports |
Ports 1~8 support IEEE802.3af/at, end-span, 30W per port Max. |
|
PoE Auto-check |
If detect the frozen PD device, restart it |
|
Working mode |
Extend mode: ports 1 ~ 8 Extend up to 250m;1 ~ 8 ports are isolated from each other and can only communicate with the uplink ports; restrain the network storm; turn off the flow control. Default mode: normal switch mode. VLAN mode: ports 1 ~ 8 are isolated from each other and can only communicate with the uplink port; restrain the network storm; turn off the flow control. |
|
1~8 PoE ports |
Support IEEE 802.3af/at, end-span, single port≦30W |
|
Cable and distance |
Use cat5e/6,100m max.(Extend mode max.250m) |
|
Standard |
IEEE802.3, IEEE802.3u, IEEE802.3z |
|
Switch fabric |
1.8Gbps |
|
Though put |
1.34Mpps |
|
Buffer |
1.25M |
|
MAC address table |
2K |
|
Indicator |
Power: 1 *red ; Uplink9, 10: On RJ45 green LEDs indicate Link/Act Downlink 1~8: On RJ45 green LEDs indicate Link/Act, yellow LEDs indicate PoE |
|
Protection |
Surge: 6KV, standard: IEC61000-4-5 ESD: 6KV: contact 8KV: air, standard:IEC61000-4-2 |
|
Working temperature |
-10℃~50℃ |
|
Storage temperature |
-40℃~85℃ |
|
Humidity |
0~95%(No condensation) |
|
Dimension(L×W×H) |
200mm×95mm×30mm |
|
Material |
Metal |
|
Colour |
Black |
|
Net-weight |
500g |
