Application Because of its excellent performance, SIMADYN D is especially suitable for all applications where a high control dynamic response and arithmetic accuracy are required or where a high level of functionality is required. SIMADYN D can be used for the widest range of applications and industry sectors as it can be freely configured and because of its extensive range of modules: • Closed-loop torque, speed and position control for converterfed DC and three-phase drives. For example, for synchronous operation, dancer or tension controls, winders, multi-motor drives, gearbox/motor test stands, complex setpoint calculations and closed-loop control for cross-cutters, "break-proof" electronic shafts • High precision rolling mill drives • Hydraulic drives with a high dynamic response • Special applications using converters, e.g. for closed-loop excitation current control, high voltage DC power transmission, static reactive power compensation equipment

Function These subracks have the following tasks: • They mechanically accommodate the modules • They supply the modules with the operating voltages • Fast data transfer between the individual modules through the L and C backplane buses • CPU, buffer memory, input/ output, expansion and communication modules can be inserted The output power of the integrated power supply is limited. For this reason it is important to observe the power requirement of the modules used (especially the current consumption at 5 V). If the power supply output available with an SR6 or SR12 is not sufficient, then the next larger subrack should be used (SR12 or SR24)

6DD1600-0AE2 SIMADYN D PROCESSOR MODULE PM12 GENERAL APPLICATION 16BI, 16BO .
6DD1600-0AE3 SIMADYN D PM13 CPU-BOARD SETPOINT CASCADE L- AND C-BUS
6DD1600-0AF0 *** SPARE PART*** SIMADYN D PROCESS MODULE PM16 GENERAL APPLICATION 16BIT16MHZ L- AND C-BUS , 16BI AL, 16BO
6DD1600-0AH0 *** SPARE PART*** SIMADYN D PROCESSOR MODULE PM4 32-BIT, GENERAL APPLICATIONS L AND C BUS, 4BI AL.
6DD1600-0AJ0 *** SPARE PART*** SIMADYN D PM5, 32-BIT CPU MODULE WITH BINARY, ABSOLUTE AND INCREMENT. INPUTS, L AND C BUS
6DD1600-0AK0 SIMADYN D PM6, RAPID 64-BIT CPU MODULE WITH BINARY INPUTS, L AND C BUS
6DD1601-0AD1 SIMADYN D DIGITAL CONTR.SYSTEM PROCESSOR MODULE PG11 LINE-COMMUTATED CONVERTERS
6DD1601-0AE0 SIMADYN D, PROCESSOR MODULE PG16 LINE-COMMUTATED CONVERTERS
6DD1602-0AE0 SIMADYN D, PROCESSOR MODULE PS16 SIMOVERT
6DD1606-0AD0 SIMADYN D TECHNOLOGY BOARD T400 FOR 6SE70/71 AND SRT400 32-BIT/32MHZ, 8BI, 2BO, 4BI/BO 5AI, 2AO;2 PULSE ENCODER INPUTS 2 SER. INTERF.+ 1 SSI ENCOD. OR 1 SER. INTERF.+ 2 SSI ENCODERS CONFIGURING WITH D7-SYS 1MB FLASH, 2MB RAM, 32KB EEPROM
6DD1606-0AD1 SIMADYN D TECHNOLOGY BOARD T400 FOR 6SE70/71 AND SRT400 32-BIT/32MHZ, 8BI, 2BO, 4BI/BO 5AI, 2AO;2 PULSE ENCODER INPUTS 2 SER. INTERF.+ 1 SSI ENCOD. OR 1 SER. INTERF.+ 2 SSI ENCODERS CONFIGURING WITH D7-SYS 1MB FLASH, 2MB RAM, 32KB EEPROM
6DD1606-1AA0 SIMADYN D PROCESSOR MODULE PT2 TECHNOLOGY
6DD1606-1AB0 SIMADYN D PROCESSOR MODULE PT2M TECHNOLOGY WITH MAILBOX
6DD1606-1AC0 SIMADYN D, PROCESSOR MODULE PT20 TECHNOLOGY 16 BIT, 20 MHZ L-BUS, 16 BI AL., 8 BI , 16 BO 7 AE , 4AO, 2 SENSING INPUTS
6DD1606-4AA0 SIMADYN D PROCESS MODULE PT32 TECHNOLOGY 32 BIT L- AND C-BUS 4 BI AL, 16 BI, 16 BO, 4 AI 4 AI INTR., 4 AO
6DD1607-0AA0 SIMATIC S7-400, FM 458 APPLICATION MODULE FOR SIMATIC S7-400
6DD1607-0AA1 SIMATIC S7-400, FM458-1 DP APPLICATION MODULE FOR SIMATIC S7-400
6DD1610-0AF0 SIMADYN D DIGITAL CONTR.SYSTEM MEMORY SUBMODULE MS3 256K BYTES EPROM
6DD1610-0AF1 SIMADYN D MEMORY SUBMODULE MS31 256 KBYTES EPROM
6DD1610-0AG0 SIMADYN D MEMORY SUBMODULE MS4 512 KBYTES EPROM, 1 WAIT STATE
6DD1610-0AG1 SIMADYN D MEMORY SUBMODULE MS41 16 BIT, 512KB EPROM,2KB EEPROM
6DD1610-0AH3 SIMATIC TDC MEMORY CARD MC521 2 MB FLASH-EPROM, 8 KB EEPROM
6DD1611-0AD0 SIMADYN D MAILBOX MM11 L- AND C-BUS , EACH 64KB RAM
6DD1611-0AG0 SIMADYN D MAILBOX MM4 , 32BIT L- AND C-BUS , EACH 2MB RAM SYSTEM ERROR SIGNAL OUTPUT
6DD1640-0AC0 SIMADYN D, INPUT OUTPUT MODULE EM11 16BIT , 8BO, 4AI, 4AI INT., 2AO PULSE SENSING
6DD1642-0BC0 SIMADYN D ANALOG OUTPUT MODULE EA12 8AO
6DD1645-0AC0
6DD1645-0AE0 SIMADYN D SIGNAL PROCESSOR MODULE EP3
6DD1648-0AB0 SIMADYN D ES1 SPECIAL BOARD VOLTAGE MONITORING RESET, BUSSTATUS
6DD1660-0AD0 SIMADYN D COMMUNICATION MODULE CS11 PARALLEL RACK COUPLING MASTER
6DD1660-0AE0 SIMADYN D COMMUNICATION MODULE CS21 PARALLEL RACK COUPLING SLAVE
6DD1660-0AH0 SIMADYN D SER. INTERFACE BOARD CS5, A12 465 660 9007.00 FOR 6SE12 SIMOVERT P
6DD1660-0AH1 SIMADYN D COMMUNICATION MODULE CS51 FOR SIMOVERT P 6SE12 AND SIMOREG K 6RA24
6DD1660-0AJ0 SIMADYN D COMMUNICATION MODULE CS6 DUST 6, SINEC L1, UNIV., 3964R
6DD1660-0AK0 SIMADYN D COMMUNICATION MODULE CS41 CONVERTER EQUIPMENT DUST6 , ET 100
6DD1660-0BA0 SIMADYN D COMMUNICATION MODULE CS12 FRAME COUPLING VIA LWL 1 RECIEVER/TRANSMITTER
6DD1660-0BD0 SIMADYN D COMMUNICATION MODULE CS22 FRAME COUPLING VIA OPTIC FIBRE CABLE
6DD1661-0AB0 SIMADYN D COMMUNICATION MODULE CSH1 SINEC H1 INTERFACE F. 16-BIT TECHNOLOGY
6DD1661-0AB1 SIMADYN D COMMUNICATION MODULE CSH11 SLAVE INTERFACE FOR BUS SYSTEM SINEC H1
6DD1662-0AB0 SIMADYN D COMMUNICATION MODULE CS7 CARRIER MODULE FOR A MAXIMUM OF 3 COMMUNICATION SUBMODULES
6DD1670-0AF0 SIMADYN D OPERATOR PANEL 0P1
6DD1672-0AB0 SIMADYN D DIGITAL CONTR.SYSTEM EPROM PROGRAMMING ADAPTER UP1 FOR PG 685
6DD1672-0AC0 SIMADYN D PROGRAMMING ADAPTER UP2 FOR PG 7..
6DD1680-0AC2 SIMADYN D SUB-D PLUG PARTS SM2.2 1X15/1X25-POLE FOR OP1
6DD1681-0AE1 SIMADYN D INTERFACE MODULE SE4.1 8BI/BO,24V,LED
6DD1681-0AE2 SIMATIC TDC, BINARY INPUT OR OUTPUT SB10 8 BI OR 8 BO , 24V DC LED DISPLAY
6DD1681-0AF4 SIMADYN D BINARY INPUT MODULE SB60 8 BI, 115V AC/DC, LED-DISPLAY, GALVANIC ISOLATION
6DD1681-0AG2 SIMATIC TDC, BINARY OUTPUT MODULE SB70 8 BO, MAX. 120V AC/DC, LED-DISPLAY, GALVANIC ISOLATION
6DD1681-0AH1 SIMADYN D INTERFACE MODULE SE7.1 8AI/AO, +-10V
6DD1681-0AJ0 SIMADYN D INTERFACE MODULE SE8 10 TERMINALS/10-POLE PLUG
6DD1681-0AJ1 SIMATIC TDC, CONVERTER SU12 10-POLE 10 SCREW-PLUGIN-TERMINALS 10-POLE PLUG
6DD1681-0AJ2 SIMADYN D CONVERTER SU14 10-PIN, ONLY FOR IT4X-MODULES 10 SCREW-PLUGIN-TERMINALS 10-POLE PLUG
6DD1681-0BD1 SIMADYN D ANALOG IN/OUTPUT MODULE SE13.1 PASSIVE SWITCHING
6DD1681-0CA2 SIMADYN D DIGITAL CONTR. SYSTEM SITOR INTERFACE SE20.2 DIRECT COUPLING FOR PG16 , PG26, PT20G
6DD1681-0CB2 SIMADYN D DIGITAL CONTR. SYSTEM INTERFACE MODULE SE21.2 SIMOVERT INTERFACE FOR PS16
6DD1681-0CD0 SIMADYN D INTERFACE MODULE SE23 40 TERMINALS/40-POLE PLUG
6DD1681-0DH0 SIMADYN D INTERFACE MODULE SE37 8BO, 24V, LED, GALVANIC ISOLATION
6DD1681-0EA1 SIMADYN D CONVERTER SU11 20-POLE 20 SCREW-PLUGIN-TERMINALS 20-POLEPLUG
6DD1681-0EB1 SIMADYN D INTERFACE MODULE SE41.1 8BI, 48V, LED, GALVANIC ISOLATION
6DD1681-0EB3 SIMATIC TDC, BINARY INPUT MODULE SB61 GALVANIC ISOLATION24/48V , 8BI 24 OR 48 V DC, LED-DISPLAY
6DD1681-0EH1 SIMADYN D INTERFACE MODULE SE47.1 BUS INTERFACE MODULE DUST 4
6DD1681-0FG0 SIMADYN D CONVERTER SU10 26-POLE 26 SCREW-PLUGIN-TERMINALS 26-POLE PLUG
6DD1681-0GK0 SIMATIC TDC, CONVERTER SU13 50 TERMINALS (1:1 CONNECTION)
6DD1682-0CC0 SIMADYN D SUBRACK SR12.1 24V DCINTEGRATED FAN 12 SLOTS , L- AND C-BUS
6DD1682-0AB1 SIMADYN D DIGITAL CONTR.SYSTEM SUBRACK SR1 24PS,W/O POWER SUPPLY UNIT/FAN
6DD1682-0AC0 SIMADYN D DIGITAL CONTR.SYSTEM SUBRACK SR2 12PS,1 FAN,W.POW.SUPPL.UNIT SP3
6DD1682-0BB1 SIMADYN D MODULE SUBRACK SR6-V 1 50/60HZ 230 V AC 6 EP, L-BUS W X H X D: 225 X 340 X 280
6DD1683 0BC0 SIMADYN D POWER SUPPLY UNIT SP8 5V/52A, 15V, 24V DC INPUT WITH FAN
6DD1683 0CC0 SIMADYN D POWER SUPPLY UNIT SP22 5V/25A, 15V, 24V DC INPUT WITH FAN
6DD1683-0BB0 SIMADYN D POWER SUPPLY UNIT SP7 5V/7A, 15V, 230V 1PH
6DD1683-0BC0 SIMADYN D POWER SUPPLY UNIT SP8 5V/52A, 15V, 24V DC INPUT WITH FAN
6DD1683-0BE0 SIMADYN D POWER SUPPLY UNIT SP9 5V/40A, 15V, 24V DC INPUT
6DD1683-0CC0 SIMADYN D POWER SUPPLY UNIT SP22 5V/25A, 15V, 24V DC INPUT WITH FAN
6DD1684-0AH0 SIMADYN D RIBBON CABLE SC7 10-POLE,L=2M
6DD1684-0BD0 SIMADYN D RIBBON CABLE SC13 40/4X10-POLE,L=2M
6DD1684-0BH2 SIMADYN D ROUND CABLE SC17.2 50-POLE, L=2M, SITOR INTERFACE SHIELDED ,PG16,PG26,PT20G SE20.2,SITOR
6DD1684-0DG1 SIMADYN D ROUND CABLE SC36.1 50-POLE, L=2.5M, CS11/CS21
6DD1684-0EA0 SIMADYN D ROUND CABLE SC40 4-POLE , L=10M,SHIELDED,SS4 PG16, PT2..-PG7.. (V.24)
6DD1688-0AD0 SIMADYN D COMMUNICATION SUBMODULE SS4 FOR CS7 , SIMADYN D PROTOCOLL DUST 1,2,3,7
6DD1688-0AE2 SIMADYN D COMMUNICATION SUBMODULE SS52 FOR CS7 , MASTER INTERFACE FOR BUS SYSTEM SINEC L2 DP
6DD1688-1AA0 SIMADYN D INTERFACE SUBMODULE SS1 20MA (TTY)
6DD1688-1AB0 SIMADYN D INTERFACE SUBMODULE SS2 SERIAL INBTERFACE V.24(EIA 232)
6DD1842-0AB1 SIMADYN D T400 WITH ANGULAR SYNCHRONOUS CONTROLLER INCL. SMALL DOCUMENTATION GERMAN/ENGLISH WITHOUT T400 ANGULAR SYNCHRONOUS CONTROL USER MANUAL
6DD2920-0AA0 TRIGGER MODULE TS12 HARDWARE-CONTROL SET FOR MECHANICAL CONVERTER 460692900000
6DD2920-0AB1 DIGITAL CONTROL SYSTEM SIMADYND INTERFACE MODULE SE48.1 FOR MAINS SIDE CONVERTER 460692900110
6DD2920-0AC0 DIGITAL CONTROL SYSTEM SIMADYND LIGHT TRANSMITTER MODULE ELE1 460692900200
6DD2920-0AD0 DIGITAL CONTROL SYSTEM SYMADYND LIGHT RECEIVER MODULE ELR1 460692900300
6DD2920-0AQ0 DIGITAL CONTROL SYSTEM SIMADYND INPUT /CHANGEOVER MODULE SU70 460692901500
6DD2920-0AR1 TRANSFORMER MODULE SA61 BUILT INTO SYNCHRONISATION MODULE SA60 460692901610
6DD2920-0AR6 SUPPLY SENSING SA20.1
6DD2920-0AS1 INTERFACE MODULE PULSE CIRCUIT WITH INTERLOOKING 460692901710
6DD2920-0XD01 BOARD IN CCU SIA
6DD3440-0AB0 SIMADYN D PROCESSOR MODULE PT10 TECHNOLOGY 16 BIT
6DD3460-0AB0 SIMADYN D BINARY AND ANALOG IN/OUT SE58 FOR PT10, 16BI,8BO,7AI,4AO 2 PULSE SENSING MODULES LED-DISPLAY
6DD3460-0AC0 SIMADYN D PULSE SENSOR SE59 FOR PT10 SUBMODULE MEMORY FOR 2 IMPULSE SENSINGS
6DD3460-0AC0 SIMADYN D PULSE SENSOR SE59 FOR PT10 SUBMODULE MEMORY FOR 2 IMPULSE SENSINGS
6DD3461-0AB0 SIMADYN D CONNECTING LEADS SC58 FOR PT10 40-POLE , L=2M, SCREENED
6DD3461-0AE0 SYMADYN D PLUG-IN CABLE SC60 FOR PT10 34-POLE, L = 2M, SCREENED
6DD3470-0AC0 SIMADYN D STANDARD PLANNING AID 6RA24/6SE12 ACCURATE SYNCHRONISM SW20 W/O OPERATING INSTRUCTIONS FEASABLE WITH AND W/O CS51
6EW1810-2AA SIMADYN D DIGITAL CONTR.SYSTEM POWER SUPPLY UNIT SP5 5V/12A, 15V, 24V DC INPUT TECHN.DATA: INPUT VOLTAGE RANGE FROM 22V TO 30VDC OUTPUT VOLT.1: +5V/12AMP. OUTPUT VOLT.2:+15V/1,0AMP. OUTPUT VOLT.3:-15V/1,0AMP.

CPU Modules

CPU modules For SIMADYN D, general open-loop and closed-loop control tasks are executed on high-performance 32 and 64-bit CPU modules with RISC processors. Both CPU modules offer a slot for Flash program memory modules MS5, MS51, MS52 (supplementary components) Buffer memory modules • The buffer memory modules provide a memory via which several CPU modules can exchange data with one another.

• Supplementary functions Up to two [expansion modules" can be mounted on the CPU modules. They provide the following supplementary functions for this CPU module: - IT41: Analog and digital inputs/outputs, incremental encoder connections - IT42: Analog and digital inputs/outputs, integrating analog inputs - ITDC: To control line-commutated converters with a SITOR interface - ITSL: SIMOLINK connection with master function • Commissioning and troubleshooting 9-pin sub-D socket (X01) on the front panel for the serial RS 232 interface for - commissioning and troubleshooting the processor program (using [Service-IBS" or the CFC test mode) - downloading the processor program with the 9-pin sub-D socket (X01)

Benefits

• By utilizing floating-point arithmetic CPU modules achieve high arithmetic accuracy.

• Configuring is simplified because normalization is not required. SIMADYN D application software programs can be very simply ported to other SIMATIC modules.

Application

PM5 CPU module for standard applications, PM6 for high-performance applications.

Buffer Memory Modules

The MM3 module makes 2 x 64 Kbyte buffer memories available to exchange data between CPU modules The module contains a clock unit which can be optionally synchronized by keys and by receiving the DCF77 time signal (radio-based clock) This clock can be used as source for all clock function blocks of the CPU modules in the subrack ("system time", max. jitter between the individual modules: 3 ms). The time and the date are used to stamp messages of a configured message system and for diagnostic messages of the operating system

■Application

Applications can be found in:

• SIMADYN systems with more that one CPU

• SIMADYN systems which require clock time

Input/Output Modules

Overview Input and output modules provide additional analog and digital inputs/outputs as well as incremental encoder connections.

■Function

• The input/output channels of different CPU modules can be used with Exxx type input/output modules by means of the L/C bus.

• ITxx expansion modules supplement the CPU modules by input/output functions. Data is not exchanged through the L/C bus, but through a direct connection to the CPU module (LE bus). This means that it is especially fast (instantaneous) and does not influence data transfer with other modules through the L/C bus. However, only this CPU module can directly use the inputs/outputs of the IT modules.
