non-barried Tyer killer barrier

Non-barried tyer killer barrier

Automatic Tyre Killer, Tyre Killer Gadget, Tyre Killer machine:

Components:

1, the application area of the key area intersection security protection

2, the overall material A3 all steel production

3, surface treatment spray paint reflective paper

4, protection grade IP67

5, the specified color black and yellow

As shown in Figure 6, the device length (intercept width) can be customized

7, device width is wide: 520mm

8, protruding ground height 70~90mm

9, the highest load weight 80T

10, the broken blade height is 120mm

11, broken blade thickness 10mm

12, sports form electromechanical

13, working environment -40 ° C ~ + 70 ° C

14, lift control short-range wireless remote control / remote control

15, control distance ≤ 100M

16, the remote control range is less than 50M

17, traffic light connection

18, linked with the gate

19, material thickness: 14 mm

20, the whole plate is formed and bent, no welding

The main technical parameters:

1, system control: 220V electric drive

2, through the pressure: can pass more than 80 tons of container trucks.

3, power supply: 220 (control voltage 24V).

As shown in Figure 4, the system power (W): 180W.

5, rise time: ≤1-2S

6, fall time: ≤ 1-2S

7, working temperature: -35 ° C ~ 75 ° C (suitable).

8, storage environment: -10 ° C ~ 65 ° C, rain, moisture and dust.

9, material: A3 steel, spray anti-rust primer.

10, color: multiple colors

11, weight: 0.5 tons

12, body specifications: standard chassis (size can be customized design)

Length 3000 × width 520 × height 70, raised height: 150

Length 3500 × width 520 × height 70, raised height: 150

Length 4000 × width 520 × height 70, raised height: 150

Length 4500 × 520 × height 70, raised height: 150

Length 5000 × width 520 × height 70, raised height: 150

Length 6000 × width 520 × height 70, raised height: 150
