Automat flap barrier gate

Flap Turnstile

(Model#STD006)

Introduction:

Flap turnstile has standard electrical interface which can be connected with ID cards, IC cards, magnetic cards, bar code cards etc. The integration system ensures passing in order and will never allow unauthorized persons to go in or go out.

Parameters:

1. Power Supply: AC220V±10V ,50Hz / AC110V±10V ,60Hz

2. Power Consumption: 100W/24V

3. Temperature: -15 to 60 degrees

4. Humidity: <95%, without concretion

5. Passage Width: 600mm

6. Passing Speed: 30 persons/min (normal open), 20 persons/min (normal close)

7. Arm Open/Close Time: 1s

8. Input Interface: +12V electrical signal or impulse signal with width more than 100ms, drive current >10mA

9. Communication Interface: RS485 (Distance: <=1200m)

10. Material: Housing - mild steel Arm – Plexiglass (soft arm)

11. Housing Dimension: 1200*300*1000mm

12. Arm Length: 250mm

13. Working Environment: Indoors or outdoors with shed

Main Functions:

1. Problem-self-checking function.

2. Arm Turning: Bi-direction

3. When power off, arm open automatically and power on again, arm will be held automatically.

4. When valid card read and passenger passed, arm can be delayed to close from 1-60s which can be set in the control panel.

5. Auto-reposition function: After card read, passenger doesn`t pass within regulated time, turnstile will cancel order automatically. And the regulated time can be set by managers.

6. Anti-rush function: if there is no open single, arm will be holding tightly.

7. Stable running with little noise.
