Customized PUR Spiral Cable Without Plug

Get Latest Price

Payment Type:: T/T, Western Union, Cash

Incoterm:: FOB, CIF, EXW

Min. Order:: 2000 Piece/Pieces

Min. Order:: 2000 Piece/Pieces

Delivery Time:: 15 Days

Transportation:: Ocean, Land, Air, Express

Port:: Yantian Shenzhen, Shekou Shenzhen

Quantity:

Your message must be between 20 to 2000 characters

Contact Now

Basic Info

Place of Origin:	Shenzhen,Guangdong
Productivity:	500000 pcs/Month
Supply Ability:	500000 pcs/Month
Payment Type:	T/T,Western Union,Cash
Incoterm:	FOB,CIF,EXW
Certificate:	TS16949;ISO13485;ISO9001
HS Code:	85441100
Transportation:	Ocean,Land,Air,Express
Port:	Yantian Shenzhen,Shekou Shenzhen

Product Description

Ideal for connecting portable audio devices to your home audio system, car stereo, portable speaker or other device that has a 3.5mm jack Customized PUR Spiral Cable Without Plug
Silver plated Plugs ensure reliability and reduce signal loss, just enjoy the high-quality stereo sound.

Customized PUR Spiral Cable Without Plug

Customized PUR Cable

Customized Spiral Cable

Spiral Cable Without Plug

Main Industry Application Products

Bone Conduction Transduer
Speed Sensor ; Angle Snesor ; Temperture Sensor ; Urea Sensor
CNC Equipment Robot Arm
AED ; Electrocardiograph

Description of Senkin Customized PUR Spiral Cable Without Plug :

Conductor Structure: See Common Conductor Structure Table Or Customization

Insulation : TPEE/FEP/MPPO/TPV/PP/HDPE

Sheath Material : General With Polyester Type TPU or Polyether Type TPU

Working Temperature : -60 Degree---125 Degree

Production Range: Standard Section 0.03-6 Square Meter Or Customization

Multiple Conductors: 1-37 Conductors Or Customization

Feature Of Customized PUR Spiral Cable Without Plug :

Flexibility
Elasticity (Spring Elongation Length Can Reach The Original Length Of 3 to 10 Times)
Cold Resistance
Flame Retardant
Oil Resistance
Abrasion Resistance.

Details HD Photo Of Customized PUR Spiral Cable Without Plug:

SK-0020S

Customized Spiral Cable

Spiral Cable Without Plug

Customized PUR Spiral Cable Without Plug

The Application Of Customized PUR Spiral Cable Without Plug:

Spiral Cable's Application On CNC Equipment&Interphone:

Base On The Features Of Our Spiral Cable--Flexibility&Oil Resistance,Many Industry Choose Our Customized PUR Spiral Cable Without Plug:

5Pin 7Pin Trailer PUR Spiral Video CableShielded Cable

Spiral Cable's Application On Medical Equipmet:

Base On The Features Of Our Spiral Cable--Flexibility&Oil Resistance,Medical Industry Choose Our Customized PUR Spiral Cable Without Plug:

5Pin 7Pin Trailer PUR Spiral Video Cable

Specification Data Sheet Of Customized PUR Spiral Cable Without Plug

P/N	Normal Spec.	Twisting OD	Resosyamce/KM	Standard OD	Conductor(Option)	Filling(Option)
10	105/0.2541/2.588	2.588	<5	3.2	99.99% Copper Tinned Copper Varnished Wire Sliver-Plated Copper Nickel Copper	Kevlar/Nylon
12	65/0.254 1/2.05	2.05	<7	2.65		Kevlar/Nylon
14	41/0.254 1/1.63	1.63	<10	2.2		Kevlar/Nylon
16	26/0.254 1/1.29	1.29	<15	1.9		Kevlar/Nylon
18	41/0.16 165/0.08 105/0.11	1.02	<25	1.6		Kevlar/Nylon
20	20/0.16 110/0.08 70/0.1	0.81	<35	1.4		Kevlar/Nylon
22	17/0.16 65/0.08 41/0.1	0.64	<55	1.2		Kevlar/Nylon
24	26/0.1 41/0.08 120/0.05	0.58	<90	1		Kevlar/Nylon
26	7/0.16 24/0.08 65/0.05	0.48	<125	0.9		Kevlar/Nylon
28	11/0.1 19/0.08 45/0.05	0.38	<210	0.85		Kevlar/Nylon
30	7/0.1 19/0.06 28/0.05 1/0.3	0.3	<320	0.7		Kevlar/Nylon
32	1/0.254 7/0.08 18/0.05	0.2	<500	0.55		Kevlar/Nylon
34	1/0.2 7/0.06	0.2	<560	0.45		Kevlar/Nylon
36	1/0.16 7/0.05	0.16	<870			Kevlar/Nylon
38	1/0.127 7/0.04	0.12	<1400			Kevlar/Nylon
40	1/0.08	0.08	<3500			Kevlar/Nylon

Specification Data Sheet Of Our High Temperature Resistant Customized PUR Spiral Cable Without Plug

P/N	Normal Spec.	Twisting OD	Resosyamce/KM	Standard OD	Conductor(Option)	Filling(Option)
10	105/0.2541/2.588	2.588	<5	3.2	99.99% Copper Tinned Copper Sliver-Plated Copper Nickel Copper	NO
12	65/0.254 1/2.05	2.05	<7	2.65		NO
14	41/0.254 1/1.63	1.63	<10	2.2		NO
16	26/0.254 1/1.29	1.29	<15	1.9		NO
18	41/0.16 165/0.08 105/0.11	1.02	<25	1.6		NO
20	20/0.16 110/0.08 70/0.1	0.81	<35	1.4		NO
22	17/0.16 65/0.08 41/0.1	0.64	<55	1.2		NO
24	26/0.1 41/0.08 120/0.05	0.58	<90	1		NO
26	7/0.16 24/0.08 65/0.05	0.48	<125	0.9		NO
28	11/0.1 19/0.08 45/0.05	0.38	<210	0.85		NO
30	7/0.1 19/0.06 28/0.05 1/0.3	0.3	<320	0.7		NO
32	1/0.254 7/0.08 18/0.05	0.2	<500	0.55		NO
34	1/0.2 7/0.06	0.2	<560	0.45		NO
36	1/0.16 7/0.05	0.16	<870			NO
38	1/0.127 7/0.04	0.12	<1400			NO
40	1/0.08	0.08	<3500			NO

Senkin Company's Info:

Helix Spring TPU Spiral Cable For Microphone

Shenzhen SenKin Electronic Co.,Ltd. has more than 10 years of experience in manufacturing cable and our major products are Silicone Cable/PTEE Cable/PUR /TPU Cable which used in the Auto,Sensors,High temperature resistance which use in Special Industry,Military Industry,Medical Industry,Robot Industry,Aerospace Industry with the monthly turnout of 500,000 meters.We handle tooling,production and packaging with the use of our eight production lines,supported by 150 staff members in our 2500 sqm factory.Our resources including production equipment and testing facilities from Taiwan and Japan enable us to turn out up to 500,000 meters monthly and provide major professional OEM service.We are always concentrate on what your request,could make the very professional suggestion and useful solution for your cable project.

PUR Jacket Spiral Cable Coiled Cable
