Contactless Smart Card Manual Sheet Collating Machine
- Payment Type:
- L/C, T/T
- Incoterm:
- FOB
- Min. Order:
- 1 Bag/Bags
- Min. Order:
- 1 Bag/Bags
- Delivery Time:
- 35 Days
- Transportation:
- Ocean, Land, Air
- Port:
- SHENZHEN
Your message must be between 20 to 2000 characters
Contact Now| Place of Origin: | CHINA |
|---|---|
| Payment Type: | L/C,T/T |
| Incoterm: | FOB |
| Certificate: | ISO, CE |
| Transportation: | Ocean,Land,Air |
| Port: | SHENZHEN |
Sheet collating machine use to stack and weld the PVC sheets before inlay laminating, adopt the electric hearting type, the pressure and time of spot welding can be adjusted, welding spot leveling ensures the quality of lamination.
Features:
1. Used for different materials position welding, including the PVC/ABS/PET etc, Just need to adjust the temperature, time and pressure.
2. Welding group position can be flexible change according to the layout, which ensures the welding quality.
3. Adopts the corner pin type for easy operation.
4. Controls and adjusts the temperature easily, temperature control is accurate.
5. The spot welding time controlled by time relay, easy and convenient to setup.
6. Camera system makes the top and bottom of materials symmetry, ensures the welding accuracy.
7. Worktable can be adjusted by 45 degree, easy for materials feeding.
Technical Parameter:
| Applicable materials: | PVC or other plastic materials (thin material) |
| Spot welding layout: | 3*8, 5*5, 4*8, 6*8, 4*10 and so on are optional |
| Spot welding heads group: | 4 groups (According to customers' requirement) |
| Layout dimension: | As customers' requirement |
| Material thickness: | 0.3-0.8 mm |
| Air pressure: | 6 kg/cm² |
|
Temperature adjustment: |
130 ℃-170 ℃ (According to the material) |
|
Time control: |
0.2~3 seconds (According to the material thickness) |
|
Power supply: |
AC 220V 50/60Hz Single phase (With earth wire) |
|
Power: |
1 KW |
| Weight: | 40 kg |
| Dimension: |
L 800*W 650*H 1200 mm |
Company Profile:
Shenzhen Yuanmingjie Technology Co., Ltd was founded in 2010 for research and development of intelligent manufacturing equipment. With many years innovations and development, Yuanmingjie has become the High Technology Corporation who has got high reputation in China and overseas. Yuanmingjie is the Shenzhen innovative enterprise and the member of Shenzhen software industry association, we also got Guangdong province credible enterprise identification.
Yuanmingjie integrated R&D, manufacturing and sales, who concentrates on supplying better equipment and supporting facilities solution for smart card factories. Our main products include production line for contact smart card, contactless smart card, dual interface smart card, RFID electrical labeling and personalized equipment.
Elites are valued by Yuanmingjie technology, lots of professionals with more than 10 years experience in equipment development gather here. With so many years of technical innovation and experience, Yuanmingjie breakthrough the traditional dependence of domestic enterprises on foreign techniques, reaches a leading position in China, who firstly adopts advanced Ultrasonic Embedding technique and Precision Vibrator Bowl. Meanwhile dual interface smart card equipment and milling and embedding two in one equipment have got National Invention Patent and CE certificate.
Spirit of Yuanmingjie: To develop ourselves by guide of market, to gain customers by credibility, to gain reputation by better quality.
Mission of Yuanmingjie: To create value for customers and society constantly.
Vision of Yuanmingjie: With continual technical innovation, wisdom and efforts from members of yuanmingjie, we will fulfill customers current need and create high needs, to be the top automatic equipment and technical solutions supplier.
