Full Auto SIM Card Punching Machine(7 station)

Feature:The full auto SIM card punching machine use the precision tool to punch the 2FF+3FF+4FF in standard SIM cards which can be full card, half card or quarter card. Also can punching a variety of non-standard card, mini card, special-shaped card, only need to change the punching tool.

Technical parameter:

Overall dimension: Approx. L 3000 x W 1000 x H 1700 mm

Weight: Approx. 2000 kg

Power supply: AC 380V 50/60Hz, 25A

Power: 0.7 kW

Air pressure: 6 kg /cm2

Air consumption: 450L/min

Accuracy of punching: ±0.05 mm

Accuracy of servo system:  Scale of servo system = 0.01mm

Specifications of Material: Laminated PVC, laminated ABS, PVC &ABS blend, other materials on request, different material need to be changed the tool, card

dimensions according to format ID-1 (ISO 7816).

Control method:           PLC+ Servo system

Production speed:

- single chip cards is up to 6.000 cards / hour,

- half card is up to 12.000 half cards / hour and for

- quarter cards up to 12.000 quarter cards / hour.

Product percent of pass: 99.8

%
