Universal 12V 3A Power Supply Adapter

Universal 12V 3A Power Supply Adapter

Universal 12V 3A Power Supply Adapter Description:

This is a 12V 3A power supply AC/DC adapter for our motion control product. It comes with adapter itself and a power cable suitable for different regions. It has 2.1mm center positive plug. It can supply ample amount of current (3000mA) to drive heavy loads, such as stepper motor, LED lightning, security surveillance system, CCTV security camera, IP camera, etc..

12V3A AC/DC universal switching power adapter

AC input 100-240Vac

Output: 12VDC 3A

100% high voltage test, 100% aging test, 100% full inspection

Built-in over current, over voltage, over load and short circuit protection

High precision, low ripple and low noise

Super-compact designed, light, handy and portable.

Multiple plug type: US/CN/EU/UK/BS/AU/KC/PSE

12V 3000mA power supply specifications:

Input: 100-240Vac 50/60Hz

Output: 12V3A

Type: Desktop

Color: Black / white

Size:96*43.5*30MM

Output loading precision: ±5%

Operating temperature: 0℃ -40℃, 5% -90% RH;

Storage temperature: -20℃ -85℃, 5% -95% RH;

Efficiency: Energy Star Level VI & ERP Stage 2 Certified

Certificate: CCC, UL, CE, FCC, CB, GS, SAA, C-tick, Rohs,

Protection: over current, over voltage, over load, short circuit protection

12V3A AC/DC power adapter Electrical:

Dielectric Withstand: 3,000VAC Primary-Secondary

Leakage Current: 0.25mA@2Pin

EMI Conduction & Radiation: Compliance to EN55022  EN55024 FCC Part 15B Class B

Harmonic Current: Compliance to EN61000-3-2

MTBF: 30,000 Calculated Hours at 25℃,by Telcordia SR-332

Output characteristics: constant current / constant voltage mode;

 images:

Company infomation :

Shenzhen Juyuanhai Electronic Co.,Ltd. was established in 2009, a professional manufacturer specialized in researching, producing and selling products like Switching power adapter, Car charger etc.So far our products have been exported to Europe, North America, Australia, Africa, Middle East and Southeast Asia. All our products enjoy very high reputation among our customers. Warmly welcome domestic and foreign customers to visit our factory and achieve win-win situation.

Certficates:
