20mm WS2811 Mini Digi Led RGB Module

Quantity:

Your message must be between 20 to 2000 characters

Contact Now

Basic Info

Place of Origin:	China
Productivity:	50000pcs/week
Supply Ability:	50000pcs/week
Payment Type:	T/T,Paypal
Incoterm:	FOB,CIF
Certificate:	CE,RoHS
HS Code:	9405409000
Transportation:	Ocean,Land,Air,express
Port:	Shenzhen,Guangzhou,HongKong

Product Description

20mm WS2811 Mini Digi Led RGB Module

Product Description

Item No. : LED-PL20SPI0101

1. 20mm Mini Led Module is regular WS2811 protocol, it's compatible of DVI led controller

2. WS2811 Mini RGB Module is 20mm diameter

3. Mini Digi Led RGB Module can be used for the sign , screen , dj booth, display, string light, curtain light

4, 20mm RGB Module is coloful and can show various color chaning effect

5, Mini Led RGB Moudle is IP67 waterproof level

6. Mini RGB Module is also for the signs, billboard, LOGO, square and street, stage, hotel, bar and disco, etc.

Parameter

Model NO.	LED-PL20SPI0101	LED-PL30SPI0301	LED-PL50SPI0601	LED-PL50SPI0601
LED type and QTY	1pcs SMD RGB 5050	3pcs SMD RGB 5050	6pcs SMD RGB 5050	6pcs SMD RGB 5050
Emitting angle	120 degree	120 degree	120 degree	120 degree
Color	■■■RGB full color	■■■RGB full color	■■■RGB full color	■■■RGB full color
Operating Voltage	DC 5V	DC 12V	DC 12V	DC 12V
Power	MAX=0.3W	MAX=0.72W	MAX=1.44W	MAX=1.44W
Control Protocol	WS2811	WS2811	WS2821	WS2811
Control Mode	DVI / Standalone Control
Dimension (housing)	20MM diameter	30MM diameter	50MM diameter	50MM diameter
Housing Material	PC	PC	PC	PC
LED Source Life	50,000 hours, based on test data of LED manufacturer
Temperature	-4℉ to 122℉(-20℃ to 50℃) operating temperature
Humidity Range	0 to 95% non-condensing
Protection	IP65	IP65	IP65	IP65
