Reserve Deep Cycle 12V vessels Battery 12V180AH
- Payment Type:
- L/C, T/T, D/P
- Incoterm:
- FOB, CFR, CIF
- Min. Order:
- 100 Piece/Pieces
- Min. Order:
- 100 Piece/Pieces
- Delivery Time:
- 30 Days
- Transportation:
- Ocean, Land
Your message must be between 20 to 2000 characters
Contact Now| Place of Origin: | china |
|---|---|
| Productivity: | 2000, 000kvah/ Year |
| Supply Ability: | 2000, 000kvah/ Year |
| Payment Type: | L/C,T/T,D/P |
| Incoterm: | FOB,CFR,CIF |
| Certificate: | iso,UL,CE |
| Transportation: | Ocean,Land |
Reserve Deep Cycle Battery LFP12180D,capacity :12V180Ah batteries is Sealed Lead Acid Battery. can be used for ForkLifts UninterruptiblePowerSupplies EmergencyLighting Wheelchairs TelecomBack-UpPowerSupplies
LawnandGardenTools EngineStarters
Specifications
|
Nominal Voltage |
12 V |
||
|
Capacity (25℃) |
10HR(10.8V) |
180 Ah |
|
|
5HR(10.5V) |
157.5Ah |
||
|
1HR(9.60V) |
113Ah |
||
|
Dimension |
Length |
494±2mm (19.45inch) |
|
|
Width |
206±2mm (8.11inch) |
||
|
Height |
209±2mm (8.23inch) |
||
|
Total Height |
T20: 235±2mm (9.25inch) |
||
|
T11: 212±2mm (8.35inch) |
|||
|
Approx. Weight |
54kg (119.1lbs)±4% |
||
|
Terminal type |
T20/T11 |
||
|
Internal resistance (Fully charged, 25℃) |
Approx. 3.3mΩ |
||
|
Capacity affected by temperature (10HR) |
40℃ |
102% |
|
|
25℃ |
100% |
||
|
0℃ |
85% |
||
|
-15℃ |
65% |
||
|
Self-discharge (25℃) |
3 month |
Remaining Capacity: 91% |
|
|
6 month |
Remaining Capacity: 82% |
||
|
12 month |
Remaining Capacity: 65% |
||
|
Nominal operating temperature |
25℃±3℃(77℉±5℉) |
||
|
Operating temperature range |
Discharge |
-15℃~50℃(5℉~122℉) |
|
|
Charge |
-10℃~50℃(14℉~122℉) |
||
|
Storage |
-20℃~50℃(-4℉~122℉) |
||
|
Float charging voltage(25℃) |
13.50 to 13.80V Temperature compensation: -18mV/℃ |
||
|
Cyclic charging voltage(25℃) |
14.50 to 14.90V Temperature compensation: -30mV/℃ |
||
|
Maximum charging current |
54A |
||
|
Terminal material |
T20: Lead, T11: Copper |
||
|
Maximum discharge current |
1400A(5 sec.) |
||
|
Designed floating life(20℃) |
12~15 years |
||
◆ Absorbent glass mat technology;
◆ Recognized by UL & CE;
◆ ABS container.
Constant Current Discharge Characteristics (A, 25℃)
|
F.V/TIME |
15min |
30min |
60min |
2h |
3h |
4h |
5h |
6h |
8h |
10h |
20h |
|
9.60V |
300 |
182 |
113 |
65.8 |
45.9 |
37.6 |
32.1 |
28.1 |
22.0 |
18.3 |
9.62 |
|
9.90V |
293 |
178 |
111 |
65.4 |
45.6 |
37.4 |
31.9 |
27.9 |
21.9 |
18.3 |
9.60 |
|
10.2V |
282 |
173 |
108 |
64.8 |
45.3 |
37.2 |
31.7 |
27.7 |
21.8 |
18.2 |
9.57 |
|
10.5V |
272 |
169 |
106 |
63.8 |
45.0 |
36.9 |
31.5 |
27.5 |
21.6 |
18.1 |
9.52 |
|
10.8V |
258 |
162 |
103 |
62.2 |
43.7 |
35.8 |
30.6 |
26.7 |
21.0 |
18.0 |
9.45 |
Constant Power Discharge Characteristics (Watt, 25℃)
|
F.V/TIME |
15min |
30min |
60min |
2h |
3h |
4h |
5h |
6h |
8h |
10h |
20h |
|
9.60V |
3294 |
2040 |
1285 |
762 |
540 |
443 |
380 |
332 |
262 |
219 |
115 |
|
9.90V |
3215 |
1999 |
1266 |
757 |
537 |
440 |
378 |
330 |
260 |
218 |
115 |
|
10.2V |
3096 |
1938 |
1234 |
750 |
533 |
437 |
375 |
328 |
258 |
218 |
115 |
|
10.5V |
2991 |
1891 |
1209 |
739 |
529 |
434 |
372 |
326 |
257 |
216 |
114 |
|
10.8V |
2833 |
1822 |
1172 |
720 |
513 |
421 |
361 |
316 |
249 |
215 |
113 |
Note: The above characteristics data can be obtained within three charge/discharge cycles.
ISO9001 approval, FN: Q3105105131
ISO14001 CTC04912E10302ROM
OHS MS18001 04912S10150ROM
UL approval, FN:MH28204
CE approval, FN:G2M20201-0102-E-16
KS approval, FN:KS C 8519
VDS approval
BS approval
FP Series Battery General Features
- Nonspillable
- Sealed and Maintenance-free Operation
- High Quality and High Reliability
- Exceptional Deep Discharge Recovery
- Low Self-discharge
- Long Service Life
- Solid Copper Terminals
- Tank-formed Plates
- Computer-aided Design and Manufacturing
- UL, CE, VdS Approved
Typical Applications
- Telecommunication equipment
- Electronic instruments
- Fire alarm
- Security devices
- UPS power supply
- Emergency lighting
