Alkaline Battery Charger 2V3000Ah
- Payment Type:
- L/C, T/T, D/P
- Incoterm:
- FOB, CFR, CIF
- Min. Order:
- 100 Piece/Pieces
- Min. Order:
- 100 Piece/Pieces
- Delivery Time:
- 30 Days
- Transportation:
- Ocean, Land
Your message must be between 20 to 2000 characters
Contact Now| Place of Origin: | china |
|---|---|
| Productivity: | 2000, 000kvah/ Year |
| Supply Ability: | 2000, 000kvah/ Year |
| Payment Type: | L/C,T/T,D/P |
| Incoterm: | FOB,CFR,CIF |
| Certificate: | iso,UL,CE |
| Transportation: | Ocean,Land |
Specifications
|
Nominal Voltage |
2 V |
||
|
Capacity (25℃) |
10HR(1.80V) |
3000 Ah |
|
|
3HR(1.75V) |
2340Ah |
||
|
1HR(1.75V) |
1609Ah |
||
|
Dimension |
Length |
576±3mm (22.68inch) |
|
|
Width |
212±2mm (8.35inch) |
||
|
Height |
772±3mm (30.39inch) |
||
|
Total Height |
807±3mm (31.77inch) |
||
|
Approx. Weight |
208.7kg (460.0lbs)±4% |
||
|
Terminal type |
T10 |
||
|
Internal resistance (Fully charged, 25℃) |
Approx. 0.13mΩ |
||
|
Capacity affected by temperature (10HR) |
40℃ |
102% |
|
|
25℃ |
100% |
||
|
0℃ |
85% |
||
|
-15℃ |
65% |
||
|
Self-discharge (25℃) |
3 month |
Remaining Capacity: 93% |
|
|
6 month |
Remaining Capacity: 85% |
||
|
12 month |
Remaining Capacity: 72% |
||
|
Nominal operating temperature |
25℃±3℃(77℉±5℉) |
||
|
Operating temperature range |
Discharge |
-15℃~50℃(5℉~122℉) |
|
|
Charge |
-10℃~50℃(14℉~122℉) |
||
|
Storage |
-20℃~50℃(-4℉~122℉) |
||
|
Float charging voltage(25℃) |
2.25 to 2.30V Temperature compensation: -3mV/℃ |
||
|
Cyclic charging voltage(25℃) |
2.30 to 2.35V Temperature compensation: -5mV/℃ |
||
|
Maximum charging current |
600A |
||
|
Terminal material |
Copper |
||
|
Maximum discharge current |
12000A(5 sec.) |
||
|
Designed floating life(20℃) |
20 years |
||
◆ Gelled electrolyte technology;
◆ Tubular Positive Plate;
◆ ABS container.
◆ Absorbent glass mat technology;
◆ Recognized by UL & CE;
◆ Suitable for higher temperature enviroment.
◆ABS container.
Constant Current Discharge Characteristics (A, 25℃)
|
F.V/TIME |
30min |
60min |
2h |
3h |
4h |
5h |
6h |
8h |
10h |
20h |
24h |
48h |
72h |
100h |
120h |
|
1.60V |
2550 |
1710 |
1035 |
796 |
643 |
548 |
471 |
370 |
305 |
162 |
139 |
74.1 |
50.5 |
37.0 |
31.5 |
|
1.65V |
2499 |
1684 |
1029 |
791 |
639 |
545 |
468 |
368 |
305 |
162 |
139 |
73.8 |
50.3 |
36.9 |
31.4 |
|
1.70V |
2423 |
1642 |
1020 |
785 |
634 |
541 |
465 |
366 |
304 |
161 |
138 |
73.5 |
50.1 |
36.8 |
31.3 |
|
1.75V |
2364 |
1609 |
1005 |
780 |
630 |
537 |
462 |
363 |
302 |
160 |
138 |
73.1 |
49.8 |
36.6 |
31.1 |
|
1.80V |
2277 |
1560 |
979 |
757 |
611 |
521 |
448 |
352 |
300 |
159 |
137 |
72.6 |
49.5 |
36.3 |
30.9 |
Constant Power Discharge Characteristics (Watt, 25℃)
|
F.V/TIME |
30min |
60min |
2h |
3h |
4h |
5h |
6h |
8h |
10h |
20h |
24h |
48h |
72h |
100h |
120h |
|
1.60V |
4769 |
3249 |
1998 |
1559 |
1259 |
1079 |
928 |
733 |
608 |
324 |
280 |
149.6 |
103.0 |
75.9 |
64.6 |
|
1.65V |
4673 |
3200 |
1986 |
1550 |
1252 |
1073 |
923 |
729 |
607 |
323 |
280 |
149.1 |
102.7 |
75.7 |
64.4 |
|
1.70V |
4530 |
3119 |
1969 |
1540 |
1243 |
1065 |
917 |
724 |
605 |
322 |
278 |
148.6 |
102.3 |
75.4 |
64.2 |
|
1.75V |
4420 |
3057 |
1939 |
1529 |
1235 |
1058 |
910 |
719 |
601 |
320 |
277 |
147.7 |
101.7 |
74.9 |
63.8 |
|
1.80V |
4258 |
2963 |
1890 |
1483 |
1198 |
1026 |
883 |
697 |
597 |
318 |
276 |
146.7 |
101.0 |
74.4 |
63.3 |
Note: The above characteristics data can be obtained within three charge/discharge cycles.
ISO9001 approval, FN: Q3105105131
ISO14001 CTC04912E10302ROM
OHS MS18001 04912S10150ROM
UL approval, FN:MH28204
CE approval, FN:G2M20201-0102-E-16
KS approval, FN:KS C 8519
VDS approval
BS approval
Typical Applications
Fire alarm systems
Solar lighting equipment
Outdoor telecommunication equipment
