LONG LIFE FP12240L BATTERY
The FP12240L Battery is desgined for general purpose and long life, focus on improving trickle life that base on FP series. Main features as follow:
When it is used in safe surroundings, the battery is maintenance free, no need adding water and it can be recharged repeatedly.
ü With isolated seal, it can be put in horizontal way, vertical way and side way, its safety and functions totally will not be affected.
ü With special formula to manufacture lead calcium alloy as well as automatic progresses, gassing will be less.
ü Long life, low self-discharge rate and high reliability.
ü It has safety, low resistance so recharge is easy and energy output is more remarkable.
ü Container material could be frame retardant ABS or PP with ranking UL 94V-0 by model.
ü Standby use.
ü High rate discharge construction.
ü Deep discharge recoverability.
ü Batteries are strictly tested by our patented computer charge/discharge system.
ü ISO9001, 14001, OHSMS 18001 certified.
ü UL recognized components under UL 1989 (file number MH14533).
ü Complies with IATA/ICAO Special Provision A67 for air transport.
ü Classified per MG Amendment 27 as a non-hazardous material for water transport.
ü Recognized by DOT as "Dry charge" 49 CFR 171-189 for surface transport.
International certifications:
- ISO9001 approval, FN: Q3105105131
- ISO14001 CTC04912E10302ROM
- OHS MS18001 04912S10150ROM
- UL approval, FN:MH28204
- CE approval, FN:G2M20201-0102-E-16
- KS approval, FN:KS C 8519
- VDS approval
- BS approval
General Features
- Nonspillable
- Sealed and Maintenance-free Operation
- Front terminal,convenience for facilitate testing and servicing.
- High Quality and High Reliability
- Exceptional Deep Discharge Recovery
- Low Self-discharge
- Long Service Life
- Solid Copper Terminals
- Tank-formed Plates
- Computer-aided Design and Manufacturing
- UL, CE, VdS Approved
Typical Applications
- Telecommunication equipment
- Electronic instruments
- UPS systems
- Solar power system
- Wind Power system
Specifications
Nominal Voltage
12 V
Capacity
(25℃)
10HR(10.8V)
24 Ah
5HR(10.5V)
22.2Ah
1HR(9.60V)
16.4Ah
Dimension
Length
166±2mm (6.54inch)
Width
175±2mm (6.89inch)
Height
125±2mm (4.92inch)
Total Height
125±2mm (4.92inch)
Approx. Weight
7.9kg (17.4lbs)±4%
Terminal type
T3/T8
Internal resistance
(Fully charged, 25℃)
Approx. 14mΩ
Capacity affected by temperature (20HR)
40℃
102%
25℃
100%
0℃
85%
-15℃
65%
Self-discharge
(25℃)
3 month
Remaining Capacity: 91%
6 month
Remaining Capacity: 82%
12 month
Remaining Capacity: 65%
Nominal operating temperature
25℃±3℃(77℉±5℉)
Operating temperature range
Discharge
-15℃~50℃(5℉~122℉)
Charge
-10℃~50℃(14℉~122℉)
Storage
-20℃~50℃(-4℉~122℉)
Float charging voltage(25℃)
13.60 to 13.80V
Temperature compensation:
-18mV/℃
Cyclic charging voltage(25℃)
14.50 to 14.90V
Temperature compensation:
-30mV/℃
Maximum charging current
7.2A
Terminal material
Copper
Maximum discharge current
360A(5 sec.)
Designed floating life(20℃)
15 years
Absorbent glass mat technology;
Recognized by UL & CE;
ABS container.
Sepecial designed floating long life -15years
Current Discharge Characteristics (A, 25℃)
|
F.V/TIME |
10min |
15min |
30min |
60min |
2h |
3h |
4h |
5h |
8h |
10h |
20h |
|
9.60V |
59.7 |
47.8 |
26.6 |
16.4 |
9.31 |
6.68 |
5.35 |
4.54 |
2.93 |
2.48 |
1.28 |
|
9.90V |
57.9 |
46.6 |
26.1 |
16.0 |
9.25 |
6.63 |
5.31 |
4.52 |
2.92 |
2.47 |
1.27 |
|
10.2V |
55.5 |
44.8 |
25.3 |
15.7 |
9.16 |
6.59 |
5.27 |
4.48 |
2.90 |
2.45 |
1.27 |
|
10.5V |
53.1 |
43.3 |
24.7 |
15.4 |
9.02 |
6.55 |
5.24 |
4.45 |
2.88 |
2.43 |
1.26 |
|
10.8V |
50.2 |
41.0 |
23.8 |
14.8 |
8.79 |
6.35 |
5.08 |
4.32 |
2.79 |
2.39 |
1.24 |
Constant Power Discharge Characteristics (Watt, 25℃)
|
F.V/TIME |
10min |
15min |
30min |
60min |
2h |
3h |
4h |
5h |
8h |
10h |
20h |
|
9.60V |
673 |
544 |
305 |
189 |
109 |
79.3 |
63.6 |
54.2 |
35.2 |
29.7 |
15.3 |
|
9.90V |
653 |
531 |
299 |
187 |
108 |
78.9 |
63.3 |
53.9 |
35.0 |
29.6 |
15.3 |
|
10.2V |
626 |
512 |
290 |
181 |
107 |
78.3 |
62.8 |
53.6 |
34.8 |
29.3 |
15.2 |
|
10.5V |
599 |
494 |
283 |
178 |
106 |
77.8 |
62.4 |
53.1 |
34.6 |
29.2 |
15.1 |
|
10.8V |
565 |
468 |
273 |
172 |
103 |
75.4 |
60.5 |
51.6 |
33.5 |
28.6 |
14.8 |
Note: The above characteristics data can be obtained within three charge/discharge cycles.
