LONG LIFE FP12180L BATTERY
THE FP12180L BATTERY is desgined for general purpose and long life, focus on improving trickle life that base on FP series. Main features as follow:
When it is used in safe surroundings, the battery is maintenance free, no need adding water and it can be recharged repeatedly.
ü With isolated seal, it can be put in horizontal way, vertical way and side way, its safety and functions totally will not be affected.
ü With special formula to manufacture lead calcium alloy as well as automatic progresses, gassing will be less.
ü Long life, low self-discharge rate and high reliability.
ü Standby use.
ü High rate discharge construction.
ü Deep discharge recoverability.
ü Batteries are strictly tested by our patented computer charge/discharge system.
ü ISO9001, 14001, OHSMS 18001 certified.
ü UL recognized components under UL 1989 (file number MH14533).
ü Complies with IATA/ICAO Special Provision A67 for air transport.
ü Classified per MG Amendment 27 as a non-hazardous material for water transport.
ü Recognized by DOT as "Dry charge" 49 CFR 171-189 for surface transport.
International certifications:
- ISO9001 approval, FN: Q3105105131
- ISO14001 CTC04912E10302ROM
- OHS MS18001 04912S10150ROM
- UL approval, FN:MH28204
- CE approval, FN:G2M20201-0102-E-16
- KS approval, FN:KS C 8519
- VDS approval
- BS approval
General Features
- Nonspillable
- Sealed and Maintenance-free Operation
- Front terminal,convenience for facilitate testing and servicing.
- High Quality and High Reliability
- Exceptional Deep Discharge Recovery
- Low Self-discharge
- Long Service Life
- Solid Copper Terminals
- Tank-formed Plates
- Computer-aided Design and Manufacturing
- UL, CE, VdS Approved
Typical Applications
-
1.UPS and EPS
2.Emergency lightp
3.Railway signal and aircraft signal system
4.Marine and power stations
5.Alarm and security system;
6.Electronic apparatus and equipment
7.Communication power supply, DC power supply
Specifications FP12180L
Nominal Voltage
12 V
Capacity
(25℃)
10HR(10.8V)
18.0Ah
5HR(10.5V)
16.8Ah
1HR(9.60V)
12.8Ah
Dimension
Length
181±2mm (7.13inch)
Width
77±1mm (3.03inch)
Height
167±2mm (6.57inch)
Total Height
167±2mm (6.57inch)
Approx. Weight
5.4kg (11.9lbs)±4%
Terminal type
T3/T8
Internal resistance
(Fully charged, 25℃)
Approx. 16mΩ
Capacity affected by temperature (20HR)
40℃
102%
25℃
100%
0℃
85%
-15℃
65%
Self-discharge
(25℃)
3 month
Remaining Capacity: 91%
6 month
Remaining Capacity: 82%
12 month
Remaining Capacity: 65%
Nominal operating temperature
25℃±3℃(77℉±5℉)
Operating temperature range
Discharge
-15℃~50℃(5℉~122℉)
Charge
-10℃~50℃(14℉~122℉)
Storage
-20℃~50℃(-4℉~122℉)
Float charging voltage(25℃)
13.60 to 13.80V
Temperature compensation:
-18mV/℃
Cyclic charging voltage(25℃)
14.50 to 14.90V
Temperature compensation:
-30mV/℃
Maximum charging current
5.4A
Terminal material
Copper
Maximum discharge current
270A(5 sec.)
Designed floating life(20℃)
15 years
Absorbent glass mat technology;
Recognized by UL & CE;
ABS container.
Sepecial designed floating long life -15years
|
F.V/TIME |
10min |
15min |
30min |
60min |
2h |
3h |
4h |
5h |
8h |
10h |
20h |
|
1.60V |
46.0 |
36.8 |
20.5 |
12.8 |
7.01 |
5.04 |
4.03 |
3.42 |
2.22 |
1.85 |
0.96 |
|
1.65V |
44.6 |
35.9 |
20.1 |
12.6 |
6.98 |
5.00 |
4.01 |
3.40 |
2.21 |
1.85 |
0.96 |
|
1.70V |
42.8 |
34.6 |
19.5 |
12.3 |
6.91 |
4.97 |
3.98 |
3.38 |
2.18 |
1.84 |
0.95 |
|
1.75V |
40.9 |
33.4 |
19.0 |
12.1 |
6.82 |
4.94 |
3.95 |
3.36 |
2.17 |
1.83 |
0.95 |
|
1.80V |
38.6 |
31.6 |
18.3 |
11.7 |
6.64 |
4.80 |
3.83 |
3.26 |
2.11 |
1.80 |
0.94 |
Constant Power Discharge Characteristics (Watt ,25℃)
|
F.V/TIME |
10min |
15min |
30min |
60min |
2h |
3h |
4h |
5h |
8h |
10h |
20h |
|
1.60V |
519 |
419 |
235 |
148 |
82.3 |
59.8 |
47.9 |
41.0 |
26.5 |
22.4 |
11.7 |
|
1.65V |
502 |
410 |
230 |
146 |
81.7 |
59.5 |
47.7 |
40.6 |
26.5 |
22.3 |
11.6 |
|
1.70V |
483 |
394 |
224 |
143 |
81.0 |
59.1 |
47.4 |
40.4 |
26.2 |
22.2 |
11.6 |
|
1.75V |
462 |
381 |
219 |
140 |
79.7 |
58.7 |
47.1 |
40.0 |
26.1 |
22.1 |
11.5 |
|
1.80V |
436 |
361 |
209 |
136 |
77.7 |
57.0 |
45.6 |
38.9 |
25.2 |
21.6 |
11.3 |
Note: The above characteristics data can be obtained within three charge/discharge cycles.
