USB2.0 Dual IDE/SATA Hard Drive Docking Station

USB2.0 Dual IDE/SATA Hard Drive Docking Station

USB 2.0 To 2.5 3.5 Inch SATA IDE Dual Slots External Hard Drive Docking Station With All In 1 Card Reader And USB 2.0 Hub Features:
● Standard, Practical, Convenient, Beautiful, Stylish Design
● USB2.0 Dual IDE / SATA Hard Drive Docking Station Supports SATA / SATA Hard Disk Dual-Bit Simultaneous Reading, Tool-Free Disassembly, Support Hot-Swappable
● USB1.1 / USB2.0 SATA I And SATA II Are Compatible With SATA ΙΙΙ
● High-Speed USB2.0 Data Transfer Rate Up To 480Mbps / Sec
● USB2.0 Dual HDD Docking IDE Sata Supports All The Capacity Of 2.5 Inch / 3.5 Inch SATA Hard Drive (Maximum Support 6TB)
● E-SATA Interface Transmission Speed Of Up To 3.0Gbps / Sec.
● SATA / IDE Dual HDD Docking Station Support Hard Disk: 2.5 ", 3.5" Serial Hard Drive Or SSD Hard Disk
● Hard Disk Drive Docking Station Support (1) CF Slot (2) SD Slot (3) TF Slot (4) MS Slot (5) XD Slot (6) Mini SD / T-Flash / Micro SD, Quick Access To Multimedia Files
● Up To 32G Memory Cards Can Be Supported
● Two Extended USB 2.0HUB Interfaces
● USB 2.0 Hard Disk Drive Docking Station Supports One-Click Offline Cloning (Not Connected To USB Port)
● The LED Indicator Can Indicate The Power And Hard Disk Read And Write Status
● Support System (Window98 / Me / 2000 / XP / Vista / Win7 / 8/10 / Mac Operating System 9.X / 10.X / Linux)
● XP System In The Maximum Support 1TB Hard Drive, WIN7 / 8/10 Above The System Can Support Up To 6TB Hard Drive

Product Overviews

Product Name: USB2.0 Dual IDE/SATA Hard Drive Docking Station

USB version: USB 2.0, compatible with USB 2.0/ 1.1
Brand: YUANKAIDA
Function: transmission
Model: JYJ-H17
Color: Black
Shell material: ABS
Product Size:  7.5 x 4.8 x 4.3 inches
Uses: laptop, pc, tablet computer
OEM / OEM: welcome
Minimum order quantity: 1000 PCS

Product Description

USB 2.0 To 2.5 3.5 Inch SATA IDE Dual Slots External Hard Drive Docking Station With All In 1 Card Reader And USB 2.0 Hub One Offline Clone Copy Instructions:
● Hard Disk Drive Docking Station, There Will Be A File SATA Hard Drive Plug In The A Drive, You Need To Copy The Data Into The Hard Disk Drive B Drive. Note: (New Hard Disk Needs To Be Formatted, B Disk Empty Hard Disk Than A Disk)
● Plug In The DC / 12V Power Supply To The Hard Disk Holder. Turn On The Power Switch And The POWER Indicator Is On. Make Sure The Hard Drive Has Turned Up.
●
USB-Dual IDE / SATA Hard Drive Docking Station Off-Line Cloning Copy A, B Are Plugged Into SATA Hard Drive (A For The Main Disk, A Disk ≤ B Disk), Turn On The Power Switch To Confirm The Hard Drive Has To Turn Up. And Then Double-Click The Red Button, Two Time Interval Of Not More Than 5 Seconds. The Red Indicator Light Flashes Up For The Clone Copy Normal. Clone Copy Of The Red Light Has Been Flashing, Red Light When The Cloning Copy Is Complete (Note: Offline Cloning Copy USB Interface Can Not Be Connected With The Computer)
● USB2.0 Dual HDD Docking IDE Sata Offline Clone Copy Hard Drive. Is Based On The Hard Disk Capacity / File Size To Distinguish Copy Of The Cloning Time.
● SATA Can Use External E-SATA Interface And Computer E-SATA Interface To Connect Data Transmission.
● SATA / IDE Dual HDD Docking Station Connects To The Hard Disk Drive And Computer With USB Cable. Open My Computer Can See The Drive Letter, Read The Red Signal When The Lights Light.
(If The New Hard Drive To Do The Following: My Computer Right / Management / Disk Management. Can Be Partitioned And Formatted.)

      Product Image

Factory Display:
