DVB-T V7400SD

Features: DVB-T free-to-air reception 4 digits LED indicates channel number and time MPEG-2 & MPEG-4 H.264 decoding OSD language: English and other languages as per request Variable aspect ratio (4:3, 16:9) 4:3 Pan & Scan or Letter Box modes Easy-to-use menu system Auto/manual channel search Support EPG Favourite Channel Edit Support teletext/subtitle/audio language selection Parental lock function Timer function Capacity for storing up to 1000 channels Full remote control function Connectors: RF input x1 RF loop through x1 SCART port (TV & VCR) x2 USB port (for recording/playback) x1(option) Video output: Component YPbPr x1 (Optional) S-Video x1 Composite x1 Audio output: Stereo L/R x1 Coaxial x1 RS232 port for firmware upgrade x1 Accessories: Remote control / User manual / battery / AV cable / Scart cable (option) Technical Specifications: System resource: Main chipset: STi5202@266MHz Memory: 8MB Flash ROM; 256MB x 2 DDR Tuner & Demodulation: Receiving frequency VHF-High : 174MHz to 230MHz UHF : 474MHz to 858MHz Input signal level: -81~-20dBm IF bandwidth: 6/7/8MHz Video demodulation: COFDM Transmission Mode: 2K FFT, 8K FFT Constellations: QPSK, 16QAM, 64QAM Code Rate: 1/2, 2/3, 3/4, 5/6, 7/8 Guards Intervals: 1/4, 1/8, 1/16, 1/32 Video decode: MPEG2 MP@HL/ML MPEG4 AVC H.264 MP@Level 3.1 Audio decode: MPEG-1/2/3, AC-3, AAC Power supply: Input voltage: AC~ 100V-240V 50/60Hz Power consumption: 15W(operating) Approvals: CE LVD, EMC, RoHS certified
