HF Multilayer Isola pcb Special High Frequency PCB Laminate

HF Multilayer Isola pcb Special High Frequency PCB Laminate Boards Specification: Material: Isola laminate Surface finish:Immersion gold,ENIG 6 layer 1.2mm thickness Green solder mask,white silk screen Line space and width:10mil Certification:ISO9001/SGS/UL Delivery time:3-7 working days Quick detail: Model:ONE-1 Size: 16*10cm Copper THK:35UM Color: Green Most popular isola model: Isola fr402,370HR,fr408,IS410 Isola pcb laminate Isola laminate Isola fr406 Isola 410 Isola 370HR Application: Automotive,Backplanes,RF / Microwave,High End Computing Signal Integrity,Medical,Military,Mobile Devices / Wireless Handsets Railway,Servers,Switches/Routers,Thermal Management,Wireless Infrastructure Parameter o. Item Spec 1 Layers 6 layers 2 Max working panel area 457 x 610 mm 3 Min board thickness 4 layer: 0.40mm 6 layer: 0.80mm 8 layer: 1.00mm 10 layer: 1.20mm 4 Min trace width 0.10mm 5 Min spacing 0.10mm 6 Min hole diameter 0.20mm 7 Min Copper thickness in hole 0.020mm 8 PTH size tolerance ±0.05mm 9 NPTH size tolerance ±0.025mm 10 Hole position tolerance ±0.05mm 11 Dimension tolerance ±0.1mm 12 Min solder mask dam 0.08mm 13 Insulation resistance 1E+12Ω (normal condition) 14 Max Board thickness/Hole size Rate '10:01 15 Thermal shock endurance 288 3 times in 10sec 16 Max Board twist and wrap ≤0.7% 17 High Vlotage endurance 1.3KV/mm 18 Copper foil peel off endurance 1.4N/mm 19 Hardness of resist ink ≥6H 20 Flame resistance 94V-0 21 Material model Isola 370HR Advantage: Have stock of Scarcity of isola 370HR material,short time of incoming material,save costing for you Place of Origin: China Brand Name: ONESEINE Certification: CE,ROHS, FCC,ISO9001 Model Number: ONESEINE Minimum Order Quantity: 1pcs Price: negotiation Packaging Details: Inner:vacuum packed bubble bag Outer:carton box Delivery Time: 5-10 days Payment Terms: T/T,western union,paypal,L/C Supply Ability: 1, 000, 000PCS/week
