LED Push button pick by light sensor
-
$50.00≥1 Piece/Pieces
- Min. Order:
- 1 Piece/Pieces
- Min. Order:
- 1 Piece/Pieces
- Transportation:
- Air
- Port:
- Shenzhen, Hongkong, Guangzhou
Your message must be between 20 to 2000 characters
Contact Now| Place of Origin: | China |
|---|---|
| Productivity: | 1000/week |
| Supply Ability: | 1000/week |
| Payment Type: | T/T,Paypal,online payment |
| Incoterm: | FOB |
| Certificate: | CE FCC ROHS |
| HS Code: | 8512201000 |
| Transportation: | Air |
| Port: | Shenzhen,Hongkong,Guangzhou |
Pick-to-Light systems dramatically increase the productivity of e-commerce order fulfillment while reducing operator errors. This type of supply chain technology has a profound impact on order picking productivity and warehouse management.
Pick-to-Light Process:
1. Start a picklist (list of inventory items to pick in order to fill one or more orders–typically started with a barcode scan)
2. Pick-to-Light hardware lights up with the SKU and quantity to pick
3. order picking by light presses the button or scans a barcode to acknowledge each pick
4. Picker repeats the process until the picklist is complete
pick to light LED, consisting of storage compartment displays, belongs to the paperless order picking methods, supports the order picker with light during order picking. The picking quantity is displayed directly at the storage compartment and confirmed at the acknowledgement button.
Light Directed Picking system used in automation, pharmacy, hospital, WMS system , supermarket .
Pick to light deviice with Anti-fall,dust-proof,long life lasting
Power: Less 5W;
Input: DC12V-30V;
Supply current:
Red, Green, Blue<75mA(12VDC); <40mA(30VDC);
Yellow, Cyan, Pink<140mA(12VDC); <70mA(30VDC);
White<205mA(12VDC); <100mA(30VDC)
IO type: Job light: Gree; Job+Sense: Yellow; Mis-picking(Sense but no job): Red.
IB intelligent bus: Indicator color customized and controlled by instruction.
TW-P3N3
Supply Voltage
12V-30Vdc
Supply Current
Red, Green, Blue:<75mA@12Vdc; <40mA@30Vdc
Output Rating:
a, Maximum Load
150mA
b, On-State Saturation Voltage
<2V(10mA dc); <2.5V(150mA)
c, Off-State Leakage Current
<10uA(30Vdc)
Indicators
7 colors available: red, green, yellow, blue white etc
I/O Type
IB intelligent bus
7 colors controlled by instruction
Electronic Protection
Protected against reverse polarity and over current
Output Response Time
25 milliseconds(max.) On and Off
Connections
M12 QD wth 0.3m cable, or 1m cable
Working temperature (℃)
-40℃~50℃
Humidity
95% at 50℃
IP rating
IP69K
Dimension
50mmx50mm(ODxH)
Mounting thread
M30x1.5mm
Material
ABS and Polycarbonate
Approval
CE FCC
Feature
Interactive touch button;
Actuated with work gloves;
Rugged, fully encapsulated IP69K construction;
7 colors available
Price is much cheaper than international brand
Job light: Green, Sense+Job light: Yellow, Mis-picking(Sense, but no job):Red
