HDMI Switcher & Splitter 4 x 8

                      HY-4408-V0-A HDMI Switcher & Splitter 4 x 8

HY-4408-V0-A HDMI Switcher & Splitter 4 x 8 Introductions:

This latest generation 4 Ports HDMI inputs / 1 MHL input and 8 HDMI outputs HDMI Switch and HDMI splitter for Ultra HD 4K. it comes with a Remote controller, AC 5V adapter and a MHL cable. Are you running a trade show and need an easy way to setup multiple HD displays showcasing your product? Do you have a sports bar or recreation center with HDTVs set up everywhere for your customers to watch the big game? Or do you just want to have a TV in every room of your house, so you do not miss a moment of your favorite TV show? This 4x8 HDMI Amplifier Splitter delivers! This is the perfect solution for when you need to distribute a video signal to multiple displays with multiple sources.

HY-4408-V0-A HDMI Switcher & Splitter 4 x 8 Features:

1. Supports 1 MHL and 3 HDMI input ports with dual mode capability.
2. Supports 8 HDMI output port.
3. Compliant with MHL2.0 and HDMI 1.4b specification.
4. Supports screen preview.
5. Supports fast switching.
6. Supports deep color 30bit, 36bit.
7. Supports Blue-Ray 24/50/60fps/HD-DVD/xvYCC.
8. Digital audio format, as DTS-HD/Dolby- trueHD/LPCM7.1/DTS/Dolby-AC3/DSD.
9. Supports signal retiming.
10. Supports Equalizer TMDS Output: 25MHz–340MHz TMDS clock.
11. Supports up to 340 MHZ TMDS clock rate( 4Kx2K) for HDMI input.
12. Supports EDID RAM.
13. Supports 1080P input up to 15 meteres AWG26 HDMI standard cable length, output up to 20 meters AWG26 cable length.
14. Inputs can be switched with the IR remote control,also can be controlled by button.
15. Extend the transmission distance and improve transmission signal.
16. Compatible with DVI through a HDMI to DVI adapter.
17. Supports hot plug-and-play.
18. LED indicate signal and power mode.
19. No loss of quality.
20. Installs in minutes.

Certificates CE FCC and RoHs

HY-4408-V0-A HDMI Switcher & Splitter 4 x 8 Specifications:

Maximum Single Link Range........................................................24/25/30fps/4Kx2K
HDMI resolution........................24/50/60fps/480i/480p/576i/576p/720p/1080i/1080p
Support video color format.............................................24bit/deep color 30bit, 36bit
Vertical Frequency Range..................................................1080p/60Hz; 4Kx2K/25Hz
Support audio format-........DTS-HD/Dolby-trueHD/LPCM7.1/DTS/Dolby- AC3/DSD
Max bandwidth...............................................................................................340MHz
Max band rate.......-...................................................................................10.2Gbps
Input/ Output TMDS signal ..................................................0. 5~ 1. 5Volts p- p( TTL)
Input/ Output DDC signal .................................................................5Volts p- p ( TTL)
1080P Input cable distance..................................≤15m AWG26 HDMI standard cable
1080P Output cable distance................................≤20m AWG26 HDMI standard cable
4KX2K Input cable distance..................................≤10m AWG24 HDMI standard cable
4KX2K Output cable distance............................... ≤15m AWG24 HDMI standard cable
Max working current...............................................................................................2.5A
Operating Temperature...........................................................................(-15 to +55℃)
Operating Humidity range............................................5 to 90% RH(No Condensation)
Dimension( L x W x H) ......................................................................275x157x25(mm)
Weight...................................................................................................................924g

Certifications: CE FCC RoHS

HY-4408-V0-A HDMI Switcher & Splitter 4 x 8 Package Content:

1. HDMI 4×8 Unit x1
2. DC 5V Power Adapter x1
3. Remote controller x1
4. User Manual x1
5. MHL Cable x1
