HDMI Splitter Switch 1 X 4 HDCP 1.3

                                          HY-1044-V0-E HDMI Splitter Switch 1 X 4 HDCP 1.3

HY-1044-V0-E 1x4 HDMI Splitter Switch 1 X 4 HDCP 1.3 Introduction:

This HDMI splitter is a product can distribute 1 way HDMI signal to 4 display terminal devices without any quality loss. It supports most of the home theater such as HDTV, blu-ray DVD, Xbox, PS3, PS4, Fire TV stick, Fire TV, ROKU, Apple TV and more other devices. It can optimize your home theater system to the best effect.

HY-1044-V0-E HDMI Splitter Switch 1 X 4 HDCP 1.3 Features:

Fully HDMI v1.4 Specification compliant. It is applicable to source device and high definition display terminal device such as DVI and HDTV which have HDMI interfaces or digital interfaces.

Compliant with HDCP 1.4 protocol, and HDMI 1.4b specification

Extends the transmission distance and improve transmission signal.

Supports 3D video (To get 3D, all units connected to the splitter outputs must support 3D)

Supports up to 4K x 2K for HDMI input and output, HD resolutions up to 4Kx2K, including 480i/p, 576i/p, 720i/p,

1080i,1080p ,Supports 12-bit Deep Full HD, Full 3D and 4K x 2K video

Compatible with DVI through a HDMI to DVI adapter

Supports hot plug-and-play

LED indicates signal and power mode

Support audio format: DTS-HD/Dolby-true HD/LPCM7.1/DTS/Dolby-AC3/DSD

Support AWG26 HDMI cable length up to 66 ft.

Support hot plug-and-play

HY-1044-V0-E HDMI Splitter Switch 1 X 4 HDCP 1.3 Specifications:

HDMI version..............................................................HDMI 1.4, HDCP 1.3

HDMI resolution ..........24/50/60fps/480i/480p/576i/576p/720p/1080i/1080p

Support video color format ....-----..24bit/deep color 30bit, 36bit, 48bit

Vertical Frequency Range..............................1080p@60Hz; 4K x 2K@30Hz

Support audio format.................................DTS-HD/Dolby-trueHD/LPCM7.1 /DTS/Dolby-AC3/DSD

Max band width............................................................................297MHz

Max band rate............................................................................8.91Gbps

Input/Output TMDS signal ........................................0.5~1.5Volts p-p(TTL)

Input/Output DDC signal....................................................5Volts p-p (TTL)

1080P Input cable distance...................≤15m AWG26 HDMI standard cable

1080P Output cable distance.................≤20m AWG26 HDMI standard cable

4KX2K Input cable distance.....................≤5m AWG24 HDMI standard cable

4KX2K Output cable distance.................≤10m AWG24 HDMI standard cable

Max working current.......................................................................500mA

Power adapter format Input:.AC (50HZ, 60HZ) 100V-240V; Output: DC5V/1A

Operating Temperature range................................................(-15 to +55℃)

Operating Humidity range---------5 to 90%RH (No Condensation)

CE FCC UL RoHs

HY-1044-V0-E HDMI Splitter Switch 1 X 4 HDCP 1.3 Package Content

1. Head unit x 1

2. Power adapter x 1

3. User manual x 1
