Various size OLED panel

Get Latest Price

Payment Type:: L/C, T/T, Western Union

Min. Order:: 500 Piece/Pieces

Min. Order:: 500 Piece/Pieces

Transportation:: Ocean, Air

Quantity:

Your message must be between 20 to 2000 characters

Contact Now

Basic Info

Place of Origin:	china
Payment Type:	L/C,T/T,Western Union
Transportation:	Ocean,Air

Product Description

Various size OLED panel, human-friendly light & unlimited design possibilities:ultra-thin,light,flexible, no glare, no uv, no heat, no blue and so on,oleds will change your light-style

OLED light panels have spectral power distributions closest to sunlight, and people feel emotionally comfortable under OLED light. Therefore, OLEDs are ideal for places where natural light is unavailable, or for places where good quality light is needed.

We wholesale and Supply a variety of sizes of OLED panels. If you are interested in them, please contact us.

Model	MP	CCT (K)	Outer size (mm)	Emitting area (mm)	Luminous Flux (lm)	Efficacy (lm/W)	Voltage (V)	DC Current (mA)	CRI (Ra)	Uniformity (%)	Thickness (mm)	Weight (g)	LT70 (hrs) 70%
Φ 100mm Rigid	18. 2	3000K	100Φ	89Φ	60	90	8.5	78	93	80	0.88	<20	40000
Φ 100mm Rigid	18. 2	4000K	100Φ	89Φ	60	75	6.0	133	93	80	0.88	<20	40000
100x100mm Rigid	17. 12	3000K	100x100	89x89	75	90	8.5	98	93	85	0.88	<20	40000
100x100mm Rigid	17. 12	4000K	100x100	89x89	75	75	6.0	166	93	85	0.88	<20	40000
300x300mm Rigid	18. 5	3000K	300x300	286x286	750	90	8.5	980	93	80	0.88	<200	40000
300x300mm Rigid	18. 5	4000K	300x300	286x286	750	75	6.0	1660	93	80	0.88	<200	40000
200x50mm Rigid	18. 4	3000K	200x50	189x39	75	90	8.5	98	93	85	0.88	<20	40000
200x50mm Rigid	18. 4	4000K	200x50	189x39	75	75	6.0	166	93	85	0.88	<20	40000
400x50mm Rigid	18. 4	3000K	400x50	389x39	150	90	8.5	196	93	80	0.88	<45	40000
400x50mm Rigid	18. 4	4000K	400x50	389x39	150	75	6.0	332	93	80	0.88	<45	40000
300x100mm Rigid	18. 1	3000K	300x100	289x86	230	90	8.5	300	93	85	0.88	<70	40000
300x100mm Rigid	18. 1	4000K	300x100	289x86	230	75	6.0	510	93	85	0.88	<70	40000
200x50mm Flexible	17. 12	3000K	200x50	189x39	75	55	8.6	160	93	85	0.41	<5	30000
200x50mm Flexible	17. 12	4000K	200x50	189x39	75	50	6.1	250	93	85	0.41	<5	20000
400x50mm Flexible	17. 10	3000K	400x50	389x39	150	55	8.6	320	93	80	0.41	<15	30000
400x50mm Flexible	17. 10	4000K	400x50	389x39	150	50	6.1	500	93	80	0.41	<15	20000
300x300mm Flexible	17. 12	3000K	300x300	286x286	750	55	8.6	1600	93	80	0.41	<76	30000
300x300mm Flexible	17. 12	4000K	300x300	286x286	750	50	6.1	2500	93	80	0.41	<76	20000

Send your message to this supplier

* From:
* To:

Ms. zhao
* Messages:

Enter between 20 to 4,000 characters.

Related Keywords

Various Size OLED Panel , OLED Panel Light , OLED Panel Lamp
